The SAUTER CP 5-3P1 is a single-point load cell in anodised aluminium for building verifiable bench and platform scales up to 5 kg. With OIML class C3 and 3000 divisions it delivers legally usable readings and carries a platform up to 250×350 mm. It is read out over a 4-wire connection with a 0,4 m cable.
Load Cell 5 kg - SAUTER CP 5-3P1
SAUTER
Original product
Net price (excl. VAT)
€47.04
Item
KER-CP 5-3P1
Personal expert advice
Brand new
Specialist dealer since 2009
Original product
Worldwide shipping
Product data
EAN4045761221246
Country of originChina
Customs tariff number84239010
ConditionNew
Article
KER-CP 5-3P1
Frequently Bought Together
-
This Item:
€47.04
-
Load Cell 500 g - SAUTER CO 0.5-Y5
€286.16
-
Load Cell 500 kg - SAUTER CS 500-3P1
€156.80
Total price
The SAUTER CP 5-3P1 is a single-point load cell in anodised aluminium for building verifiable bench and platform scales up to 5 kg. With OIML class C3 and 3000 divisions it delivers legally usable readings and carries a platform up to 250×350 mm.
Benefits
- Suitable for verified scales: OIML class C3 with 3000 divisions (e)
- Light, corrosion-protected body: made from anodised aluminium
- Platform up to 250×350 mm: fits price-computing, bench and platform scales
- Ready to wire: 0,4 m cable, 4-wire technology
- Wide temperature range: -35 to 65 degrees Celsius
- Higher accuracy on request: OIML R60 class C4/C5
Technical data
- Rated capacity (Max): 5 kg
- OIML class: C3
- Resolution (verifiable): 3000 e
- Y-value: 10000
- Force direction: compression
- Max. platform size: 250×350 mm
- Cable length: 0,4 m
- Connection: 4-wire
- Operating temperature: -35 to 65 degrees Celsius
- Weight: 0,20 kg
- Material: anodised aluminium
Applications
Typical fields of use are industry and manufacturing, the packaging industry, food and pharma, mechanical and plant engineering and research and development.
Compliance and origin
EAN 4045761221246, customs tariff number 84239010, country of origin China.
| Manufacturer | Sauter |
|---|---|
| Country of Manufacture | China |
| EAN | 4045761221246 |
| Weight | 0.250000 |
| HS-Code | 84239010 |
| GPSR manufacturer information | A1-ESD equipment GmbH. Keldersstr. 15, DE-42697 Solingen, www.esd.equipment |
| Article authenticity | Original product |
| Condition of article | New |
| Wägebereich max (g) | 5000.000000 |
| Position sensing | No |
