APL Universal 1500 basic sense LED system luminaire 1,472 mm, 4,538 lm, motion detector - Spelsberg 5250132085
LED system and machine luminaire APL Universal 1500 basic sense, 1,472 mm long, featuring a microprism diffuser. It delivers 4,538 lm at 40.1 W and 5,000 K, with Ra > 80 and UGR < 22. Fitted with an integrated motion detector. Connection cable not included.
- Specialist dealer since 2009
- Invoice payment for regular customers
- Worldwide shipping
- Technical questions clarified with the manufacturer
Description
The Spelsberg APL Universal 1500 basic sense is an LED luminaire for workstations, machines and systems - 1,472 mm long with a 70 x 80 mm profile and housed in clear anodised aluminium. Its microprism diffuser spreads the light evenly and also performs well above shiny, reflective workpieces. Drawing 40.1 W of system power, it provides 4,538 lm and a maximum illuminance of 1,733 lx at a colour temperature of 5,000 K, with colour rendering Ra > 80 and a glare rating of UGR < 22. A motion detector is built in, which makes the luminaire 32 mm longer than the version without sensor. Weight: 3.69 kg.
Features
- Microprism diffuser for homogeneous illumination, suitable for reflective surfaces
- Colour rendering Ra > 80, glare rating UGR < 22
- Integrated motion detector (luminaire 32 mm longer than without sensor)
- Clear anodised aluminium housing, protection rating IP40
- Service life L80/B10 at 75,000 h
- Made in Germany
Applications
- Assembly, inspection and testing workstations
- Lighting on machines and systems
- Work on glossy or reflective parts
- Workstations that are not permanently occupied
- Workbenches and work tables in production, including ESD workstations
Technical data
| Article number | 5250132085 |
|---|---|
| Product line | APL Universal 1500 basic sense |
| Light control | Microprism diffuser |
| Luminous flux | 4,538 lm |
| System power | 40.1 W |
| Max. illuminance | 1,733 lx |
| Colour temperature | 5,000 K |
| Colour rendering | Ra > 80 |
| Glare rating | UGR < 22 |
| Service life | L80/B10 at 75,000 h |
| Energy efficiency class (light source) | C |
| Dimensions (L x W x H) | 1,472 x 70 x 80 mm |
| Weight | 3.69 kg |
| Protection rating | IP40 |
| Mains voltage | 220-240 V AC, 50-60 Hz |
| Housing | Aluminium, clear anodised |
| Mounting | Surface-mounted version |
| Operation | Motion detector |
| Connection cable | not included (accessory: 4 m with Schuko plug) |
| EAN | 4262461991808 |
| Manufacturer | Spelsberg |
| Manufacturer Nr. | 5250132085 |
| HS-Code | 94054239 |
| GPSR manufacturer information | Spelsberg Lichttechnik GmbH & Co. KG, Gewerbering 12, DE-58579 Schalksmühle, www.spelsberg-lichttechnik.de |
| Condition of article | New |
| Article authenticity | Original product |
| Country of Manufacture | Germany |
| ESD version | TEC |
| Luminous flux (lumen) | 538 lm |
| Power (W) | 40.1 W |
| Colour rendering (Ra) | Ra 80 |
| Operating voltage | 220-240 V |
| Series | APL Universal |
| Protection class (IP) | IP40 |
Scope of delivery
- 1 × APL Universal 1500 basic sense
- 1 mounting kit (standard)
Not included: the connection cable (4 m, with Schuko plug and socket connector) must be ordered separately as a recommended accessory.
