LED high bay luminaire ACANEO HIAL 30000/840/N/DALI, 206 W, 33,000 lm, 48° narrow beam, DALI dimmable - Waldmann 113533000-00732988

Tall production and storage halls need a lot of light per luminaire: the ACANEO HIAL 30000/840/N/DALI produces approx. 33,000 lm at approx. 206 W and reaches approx. 160 lm/W, so fewer luminaires cover the same floor area. The 48° optic concentrates the light precisely on floors, work areas and rack aisles. Its DALI ballast allows continuous dimming and integration into a lighting management system.

Benefits

• 48° narrow beam optic: directs light from great heights onto work areas and into narrow aisles
• Continuously dimmable via DALI, for daylight or presence control with a matching sensor
• 4000 K neutral white light, CRI ≥ 80 and chromaticity tolerance < 3 SDCM for consistent light throughout the hall
• IP65, protection class I and operation at ambient temperatures from -30 °C to 60 °C, also for unheated halls and cold areas

Applications

• High-bay warehouses and logistics halls with narrow aisles
• Production halls with great mounting heights
• Halls with crane runways and high ceilings
• Halls with lighting management or zone control

Installation and accessories

• Fastening available separately: ceiling bracket, 1-point suspension, trapezoidal hanger or wire rope with wire rope holder
• Mains connection via built-in plug RST 20i5, junction box RST 20i5 and safety glass available as accessories
• Sensors with surface-mounting adaptor and Netcomposer control (NCR) from the ACANEO accessories
