LED high-bay luminaire ACANEO HIAL 30000/840/N/EA, 33,000 lm, 4000 K, 48°, switchable

Images are examples, some edited with AI. The technical data are authoritative. AI notice

LED high-bay luminaire ACANEO HIAL 30000/840/N/EA, 33,000 lm, 4000 K, 48°, switchable - Waldmann 113535000-00734099

Name: LED high-bay luminaire ACANEO HIAL 30000/840/N/EA, 33,000 lm, 4000 K, 48°, switchable - Waldmann 113535000-00734099
Brand: Waldmann
SKU: WAL-113535000-00734099
Price: 1275.00 EUR
Availability: InStock

Waldmann ✓ Original product Brand new Made in Germany

ACANEO HIAL 30000/840/N/EA LED high-bay luminaire with approx. 33,000 lm at 206 W, 4000 K and narrow 48° optics, switchable. For very high production and logistics halls, IP65.

Net

€1,275.00

excl. VAT

Item WAL-113535000-00734099

Manufacturer no. 113535000-00734099

Question about this item

Datasheet (PDF) User manual 6 documents, all under Downloads

Specialist dealer since 2009
Invoice payment for regular customers
Worldwide shipping
Technical questions clarified with the manufacturer

Description

Very high halls need a lot of luminous flux per light point so that enough reaches the floor. The ACANEO HIAL 30000/840/N/EA delivers approx. 33,000 lm at 206 W and approx. 160 lm/W, with narrow 48° optics and neutral white 4000 K.

Benefits

High luminous flux per luminaire: approx. 33,000 lm at 206 W, 160 lm/W luminous efficiency
Aluminium housing, powder-coated in white aluminium, IP65 and protection class I, usable from -30 °C to 50 °C
Narrow-beam symmetric optics with 48°, UGR ≤ 22, luminance L65 ≤ 6300 cd/m²
LED life L80B50 60,000 h, chromaticity tolerance < 3 SDCM, CRI ≥ 80
Plug-in connection via RST 25i3 connector with matching junction box

Applications

Production halls with high ceilings
Logistics centres and high-bay warehouses
Halls exposed to coolants, oils or welding fumes (resistant according to the manufacturer)

Installation and accessories

Fastening available separately: ceiling mounting bracket (adjustable), 1-point suspension with wire ropes, wire rope holder and trapezoidal hanger with M8 thread
Mains connection via RST 25i3 connector, RST 25i3 junction box as accessory
Safety glass panels 585 x 480 mm and 480 x 405 mm available as accessories

Technical data

Manufacturer part no.	113535000-00734099
Order number	00734099
EAN	4013330108021
Connected load	220-240 V, AC, 50 Hz, 60 Hz
Control gear	Electronic ballast
Power consumption	Approx. 206 W
Luminous flux	Approx. 33,000 lm
Luminous efficiency	Approx. 160 lm/W
Light type/colour	Neutral white
Colour temperature	Approx. 4000 K
Color rendering index	CRI ≥ 80
Light distribution	Narrow-beam, Direct, Symmetric, approx. 100 %
Beam angle	48 °
Glare control	Optics
Light source	LED
Life expectancy LED	L80B50 60,000 h
Chromaticity tolerance LED	< 3 SDCM
At-risk group	RG0/1
Luminance (L65)	≤ 6300 cd/m²
UGR class (4H 8H, EN 12464-1)	≤ 22
System of protection/Class	IP 65, I
Technology	Switchable
Operation	External
Housing	Aluminium, Powder-coated, White aluminium
Light source cover	Acrylic (PMMA), Clear
Mains lead	Built-in plug, RST 25i3 panel-mount connector
Design	Mounted version
Fastening	Available separately
Accessory	Junction box (RST 25i3)
Ambient temperature min./max	-30 °C, 50 °C
Decorative contrast side parts	Jet black
Weight without/incl. packaging	10.8 kg / approx. 13.8 kg
Packaging dimensions LxWxH	642 x 525 x 250 mm
Power factor	Approx. 0.973
Weight	13.8 kg
Manufacturer	Waldmann
Manufacturer Nr.	113535000-00734099
HS-Code	94051140
GPSR manufacturer information	WALDMANN Lichttechnik Peter-Henlein-Straße 5 DE-78056 Villingen-Schwenningen
Condition of article	New
Article authenticity	Original product
Country of Manufacture	Germany
Sales unit	1 Stück
Colour	White
Farbe	Weißaluminium
Luminous flux (lumen)	33000 lm
Power (W)	206 W
Colour rendering (Ra)	Ra 80
Operating voltage	220-240 V
Series	ACANEO
Protection class (IP)	IP65
