LED tube luminaire RL70LE-120 N, 230 V AC, 5200 lm, 1210 mm, polycarbonate - Waldmann 113628000-00748844

For long working areas and wide system sections, the RL70LE-120 N delivers 5200 lm at 81 lm/W over an overall length of 1210 mm. The clear polycarbonate tube is intended for areas close to food products. It connects directly to 230 V AC without a separate operating device, so it also suits systems that have no 24 V supply.

Benefits

• Light Forming technology with diffuser spreads the light across 1156 mm of light output at a 100° beam angle, luminance L65 ≤ 18,000 cd/m²
• Clear polycarbonate tube with IP67 protection for areas close to food products
• 5200 lm at 64 W power consumption, luminous efficiency 81 lm/W, 5000 K neutral white, CRI ≥ 80
• Direct mains connection to 230 V AC, 50/60 Hz via series 272 connector, protection class I

Applications

• Machines in areas close to food products
• Packaging systems
• Food processing systems

Installation and accessories

• Mounting with pipe clamp (accessory)
• Mains connection via series 272 connector, screwed cable gland on side part A
• Matching luminaire brackets, also with rubber profile or in stainless steel
• No additional operating device required
