LED pendant luminaire IDOO.line ILP 3000/840/D, start luminaire, 3150 lm, 4000 K, 1128 mm, white - Waldmann 114144000-00805688

Planning a continuous light line above workstations starts with this start luminaire: the ILP 3000/840/D comes with an approx. 2 m mains lead and, thanks to through-wiring, supplies up to 18 m of light line from a single connection. The 1128 mm module delivers 3150 lm at 23 W, which equals 136 lm/W. Neutral white 4000 K with CRI ≥ 80 matches what is usually specified for screen and administrative workstations. The white aluminium profile blends in below light ceilings.

Benefits

• 3150 lm at 23 W: 136 lm/W luminous efficiency, energy efficiency class C.
• Direct/indirect with approx. 40 % direct share: prism aperture, UGR ≤ 16 and max. 2700 cd/m² luminance (L65) keep glare off screens, the indirect share brightens the ceiling.
• One mains connection for up to 18 m: further modules run on the through-wiring and need no separate supply.
• DALI and TouchDIM: digitally dimmable ballast (DALI load 1x), dimming range 1-100 %, alternatively via a standard push button.
• Flicker-free with consistent colour: chromaticity tolerance < 3 SDCM, LED life L90B50 50,000 h, suitable as emergency lighting.

Applications

• Double workstations and medium-sized meeting tables
• Screen workstations in the office
• Administration and clerical work
• Laboratories and practice rooms with desk work

Installation and accessories

• Suspended mounting on steel cable 0.3-0.7 m
• Mains connection via approx. 2 m lead with free stranded wires at the start of the line
• Combines with IDOO.line start, middle and end luminaires, up to 18 m on one mains connection
• Control via DALI or a standard push button (TouchDIM)
• Weight without packaging 4.1 kg
