LED pendant luminaire DOTOO.line DLP 2000/830/D, 16 W, 1650 lm, warm white

Images are examples, some edited with AI. The technical data are authoritative. AI notice

LED pendant luminaire DOTOO.line DLP 2000/830/D, 16 W, 1650 lm, warm white - Waldmann 114254000-00805850

Name: LED pendant luminaire DOTOO.line DLP 2000/830/D, 16 W, 1650 lm, warm white - Waldmann 114254000-00805850
Brand: Waldmann
SKU: WAL-114254000-00805850
Price: 563.17 EUR
Availability: InStock

Waldmann ✓ Original product Brand new Made in Germany

Pendant luminaire from the DOTOO.line modular system: 16 W, 1650 lm, warm white. Continuously dimmable, flicker-free, up to 18 m of line on one mains connection. For meeting rooms, reception and practices.

Net

€563.17

excl. VAT

Item WAL-114254000-00805850

Manufacturer no. 114254000-00805850

Question about this item

Datasheet (PDF) User manual 6 documents, all under Downloads

Specialist dealer since 2009
Invoice payment for regular customers
Worldwide shipping
Technical questions clarified with the manufacturer

Description

The DLP 2000/830/D is a pendant luminaire from the DOTOO.line modular system for continuous light lines of up to 18 m on one mains connection. At 16 W it delivers around 1650 lm of warm white light, about 103 lm/W.

Benefits

Through-wired, up to 18 m on one mains connection, modules linked without tools
Continuously dimmable, also via a standard push switch (TouchDIM)
Prism aperture and luminance L65 ≤ 3000 cd/m² for low-glare screen work
Around 103 lm/W luminous efficacy
Flicker-free light

Applications

Meeting and conference rooms
Reception and waiting areas in practices
Offices with a residential feel
Administration and libraries

Installation and accessories

Suspended on steel cables 0.3-0.7 m
Tool-free mechanical and electrical connection of the modules, up to 18 m on one mains connection
Dimming via a standard push switch

Technical data

Manufacturer part no.	114254000-00805850
Order number	00805850
EAN	4013330036782
Connected load	220-240 V
Control gear	Electronic ballast
Power consumption	approx. 16 W
Luminous flux	approx. 1650 lm
Luminous efficiency	approx. 103 lm/W
Light colour	Warm white
Light distribution	Direct
Life expectancy LED	L90B50 50,000 h
Energy efficiency class	C
At-risk group	RG0/1
Luminance (L65)	≤ 3000 cd/m²
Technology	Continuously dimmable
Operation	External
Fastening	Steel cable 0.3-0.7 m
Weight without/incl. packaging	4.6 / approx. 6.1 kg
Power factor	approx. 0.98
Special features	Flicker-free, DALI Load 1x, Suitable as emergency lighting, Through-wired, up to 18 m on one mains connection, Mechanical and electrical connection of the individual modules without tools, TouchDIM - dimming via standard switch
Weight	6.1 kg
Manufacturer	Waldmann
Manufacturer Nr.	114254000-00805850
HS-Code	94051140
GPSR manufacturer information	WALDMANN Lichttechnik Peter-Henlein-Straße 5 DE-78056 Villingen-Schwenningen
Condition of article	New
Article authenticity	Original product
Country of Manufacture	Germany
Sales unit	1 Stück
Control and dimming	Dimmable
Luminous flux (lumen)	1650 lm
Power (W)	16 W
Mounting type	Pendant
Operating voltage	220-240 V
Series	DOTOO.line
