LED pendant luminaire IDOO.line ILP 6000/830/D, middle luminaire, 6000 lm, 3000 K, 2244 mm, white - Waldmann 114188000-00805745

The ILP 6000/830/D middle luminaire extends an IDOO.line light line by 2244 mm and 6000 lm without an additional mains connection: it is coupled mechanically and electrically to the neighbouring module without tools. At 46 W it reaches 130 lm/W. Warm white 3000 K with CRI ≥ 80 creates a calm lighting mood for meetings, reception and waiting areas. The white aluminium profile blends in below light ceilings.

Benefits

• 6000 lm at 46 W: 130 lm/W luminous efficiency, energy efficiency class C.
• Direct/indirect with approx. 40 % direct share: prism aperture, UGR ≤ 16 and max. 2700 cd/m² luminance (L65) keep glare off screens, the indirect share brightens the ceiling.
• Tool-free coupling: mechanical and electrical connection without tools, no separate mains connection needed.
• DALI and TouchDIM: digitally dimmable ballast (DALI load 1x), dimming range 1-100 %, alternatively via a standard push button.
• Flicker-free with consistent colour: chromaticity tolerance < 3 SDCM, LED life L90B50 50,000 h, suitable as emergency lighting.

Applications

• Long light lines in open-plan offices, administration corridors and training rooms
• Meeting and conference rooms
• Reception and waiting areas in medical practices
• Break rooms and lounges

Installation and accessories

• Suspended mounting on steel cable 0.3-0.7 m
• Positioned within the line as middle luminaire, supplied via the through-wiring
• Combines with IDOO.line start, middle and end luminaires, up to 18 m on one mains connection
• Control via DALI or a standard push button (TouchDIM)
• Weight without packaging 7.5 kg
