LED pendant luminaire DOTOO.line DLP 2000/830/D, linking module, 16 W, 1650 lm, 3000 K, silver, 1402 mm - Waldmann 114253000-00805849

This module extends a DOTOO.line light line fed by a start luminaire: it plugs in mechanically and electrically without tools and is powered through the through-wiring. At 16 W it emits approx. 1650 lm (103 lm/W) with warm white light at 3000 K. With a length of 1402 mm, a few modules cover a long row of desks, which saves suspension points. The silver housing makes the light line stand out against dark or exposed ceilings.

Benefits

• Tool-free linking: mechanical and electrical connection to the adjacent module without tools, power comes through the through-wiring of the line.
• Emergency lighting capable: can be integrated into safety lighting, IP40 protection for dry indoor rooms.
• Glare control for screen work: prismatic diffuser in clear PMMA, luminance ≤ 3000 cd/m² at 65° and UGR ≤ 19 to EN 12464-1.
• DALI or push-button: digitally dimmable DALI ballast (DALI load 1x) for lighting management, alternatively TouchDIM via a standard push-button.

Applications

• Long rows of desks in offices and administration
• Libraries and reading areas
• Meeting and conference rooms

Installation and accessories

• Suspension on steel cable, 0.3-0.7 m
• Connection with free stranded wires, the line is fed by a DOTOO.line start luminaire
• Combines with start, middle and end luminaires of the DOTOO.line modular system
