LED pendant luminaire DOTOO.line DLP 1500/830/D, middle luminaire 90° left, 13 W, 1300 lm, 3000 K, silver, 600 mm - Waldmann 114332000-00807698

When the light line has to follow an L-shaped desk layout or turn a corner, this 600 mm middle luminaire provides the 90° continuation to the left (as seen from above). Light runs through the corner without a dark zone, with approx. 1300 lm at 13 W and warm white light at 3000 K. The silver aluminium profile suits rooms with glass and metal elements or open ceilings.

Benefits

• No gap at the corner: 90° continuation to the left, continuous light without a dark zone, beam angle 86°.
• Glare control for screen work: prismatic diffuser in clear PMMA, luminance ≤ 3000 cd/m² at 65° and UGR ≤ 19 to EN 12464-1.
• DALI or push-button: digitally dimmable DALI ballast (DALI load 1x) for lighting management, alternatively TouchDIM via a standard push-button, dimming range 1-100 %.
• Consistent white along the whole line: flicker-free, CRI ≥ 80 and colour tolerance < 3 SDCM between adjacent modules.

Applications

• L- and U-shaped workstation clusters
• Meeting and conference rooms
• Reception and waiting areas in medical practices

Installation and accessories

• Suspension on steel cable, 0.3-0.7 m
• Power supplied through the through-wiring of the linked line, 220-240 V, 50/60 Hz
• Combines with start, middle and end luminaires of the DOTOO.line modular system
