LED pendant luminaire DOTOO.line DLP 1500/830/D, 90° middle luminaire, 13 W, 1300 lm, silver - Waldmann 114333000-00807699

The DLP 1500/830/D is the corner module of the DOTOO.line: a 600 mm middle luminaire with a 90° continuation to the right (seen from above) that carries the light round the corner without a dark zone. At 13 W it reaches about 1300 lm. The silver aluminium profile gives the line a technical, matter-of-fact look. Warm white light at 3000 K creates a calm setting in meeting rooms, reception areas and practices.

Benefits

• 90° continuation to the right (seen from above) with continuous light and no dark zone in the corner
• Prism aperture and luminance L65 ≤ 3000 cd/m², UGR ≤ 19, for low-glare screen work
• Around 100 lm/W luminous efficacy, standby ≤ 0.2 W
• Flicker-free light, CRI ≥ 80 and chromaticity tolerance < 3 SDCM, so adjacent modules match in colour
• Suitable as emergency lighting, LED life expectancy L90B50 50,000 h

Applications

• Meeting and conference rooms
• Reception and waiting areas in practices
• Offices with a residential feel
• L-shaped desk layouts and room corners

Installation and accessories

• Suspended on steel cables 0.3-0.7 m
• Tool-free mechanical and electrical connection, supplied via the start luminaire of the line
• Combine with a DOTOO.line start luminaire and end luminaire
• Dimming via DALI or a standard push switch
