LED pendant luminaire IDOO.line ILP 3000/830/D, 90° middle luminaire left, 3000 lm, 3000 K, silver - Waldmann 114340000-00807706

When a light line has to turn a corner, the ILP 3000/830/D takes over: this middle luminaire continues the line at 90° to the left (seen from above) and provides continuous light without a dark zone at the joint. It delivers 3000 lm at 23 W (130 lm/W). Warm white 3000 K with CRI ≥ 80 creates a calm lighting mood for meetings, reception and waiting areas. The silver aluminium profile goes well with metal and glass surfaces in the room.

Benefits

• 3000 lm at 23 W: 130 lm/W luminous efficiency, energy efficiency class C.
• Direct/indirect with approx. 40 % direct share: prism aperture, UGR ≤ 16 and max. 2700 cd/m² luminance (L65) keep glare off screens, the indirect share brightens the ceiling.
• 90° continuation to the left: the line turns the corner without a dark zone.
• DALI and TouchDIM: digitally dimmable ballast (DALI load 1x), dimming range 1-100 %, alternatively via a standard push button.
• Flicker-free with consistent colour: chromaticity tolerance < 3 SDCM, LED life L90B50 50,000 h, suitable as emergency lighting.

Applications

• Corners above L- or U-shaped desk arrangements
• Meeting and conference rooms
• Reception and waiting areas in medical practices
• Break rooms and lounges

Installation and accessories

• Suspended mounting on steel cable 0.3-0.7 m
• Positioned as middle luminaire at the corner, 90° continuation to the left
• Combines with IDOO.line start, middle and end luminaires, up to 18 m on one mains connection
• Control via DALI or a standard push button (TouchDIM)
• Weight without packaging 4.5 kg
