LED pendant luminaire IDOO.line ILP 3000/VTL/D, Tunable White, 3150 lm, 90° middle luminaire, white - Waldmann 114343000-00807709

Where a Tunable White light line has to turn a corner, this white middle luminaire provides the 90° continuation on the right side without a dark zone. It delivers approx. 3150 lm at 32 W and adjusts the light colour between 2700 and 6500 K via a DALI ballast.

Benefits

• Tunable White 2700-6500 K via DALI Device Type 8: constant luminous flux across the whole range and constant colour temperature at every dimming level.
• 90° continuation on the right side (top view) with continuous light and no dark zone at the corner.
• CRI ≥ 90, colour tolerance < 3 SDCM and flicker-free light for comfortable vision.
• Prism aperture, UGR ≤ 16 (4H 8H, EN 12464-1) and luminance L65 ≤ 2700 cd/m²: designed for screen workstations.
• Digitally dimmable DALI ballast, dimming range 3-100 %.

Applications

• L-shaped rooms and corner desk groups
• Offices with time-of-day lighting control
• Medical practices and care facilities
• Meeting rooms

Installation and accessories

• Suspension via steel cable 0.3-0.7 m.
• Corner module without its own mains connection in the data sheet, supplied via the through-wired line.
• Combines with IDOO.line start, middle and end luminaires.
• Tunable White requires an external control for DALI Device Type 8.
