LED surface-mounted luminaire DOTOO.line DLA 1000/840/D, middle luminaire, 1000 lm, white - Waldmann 114349000-00807926

As a middle luminaire it extends a line between start and end luminaire by 842 mm, through-wired and plugged in without tools. The DLA 1000/840/D delivers neutral white light at 4000 K with 1000 lm from 9.5 W, which equals around 105 lm/W. The white aluminium profile blends into light-coloured ceilings. The prism aperture keeps glare at UGR ≤ 19.

Benefits

• Through-wired: 842 mm of extra line without its own mains connection
• DALI ballast, continuously dimmable, alternatively via a standard push button (TouchDIM)
• Prism aperture with UGR ≤ 19 and luminance ≤ 3000 cd/m² at 65°, suitable for screen work
• Flicker-free, CRI ≥ 80 and chromaticity tolerance < 3 SDCM for a uniform light colour across all modules
• Suitable for emergency lighting, LED life L90B50 50,000 h
• 1000 lm at 9.5 W, around 105 lm/W: low connected load per metre of light line

Applications

• Offices and VDU workstations
• Laboratories and treatment rooms
• Administration and back office
• Short room axes, alcoves and counters

Installation and accessories

• Ceiling mounting as a surface-mounted version, aluminium profile with clear PMMA cover
• Fitted between start and end luminaire, supplied via the through-wiring
• Matching DALI accessories: IR-Quattro-HD-DALI presence detector with AP-Box, DALI MCU rotary dimmer, RC 5 DALI remote control
