LED surface-mounted luminaire DOTOO.line DLA 1000/830/D middle luminaire, 10 W, 1000 lm, white

Images are examples, some edited with AI. The technical data are authoritative. AI notice

LED surface-mounted luminaire DOTOO.line DLA 1000/830/D middle luminaire, 10 W, 1000 lm, white - Waldmann 114361000-00807938

Name: LED surface-mounted luminaire DOTOO.line DLA 1000/830/D middle luminaire, 10 W, 1000 lm, white - Waldmann 114361000-00807938
Brand: Waldmann
SKU: WAL-114361000-00807938
Price: 440.69 EUR
Availability: InStock

Waldmann ✓ Original product Brand new Made in Germany

Middle luminaire for the DOTOO.line surface-mounted light line, 842 mm long, delivering approx. 1000 lm at 10 W in warm white 3000 K. It extends the line without a supply cable of its own. White aluminium housing, DALI dimmable, for meeting rooms, practices and care settings.

Net

€440.69

excl. VAT

Item WAL-114361000-00807938

Manufacturer no. 114361000-00807938

Question about this item

Datasheet (PDF) User manual 6 documents, all under Downloads

Specialist dealer since 2009
Invoice payment for regular customers
Worldwide shipping
Technical questions clarified with the manufacturer

Description

This 842 mm module suits short light lines above a single desk. As a middle luminaire it extends the line between start and end luminaires, with no mains connection of its own. It delivers approx. 1000 lm at 10 W (around 100 lm/W) in warm white 3000 K.

Benefits

No supply cable of its own: power and DALI signal arrive via the through-wiring.
Modules connect mechanically and electrically without tools.
Warm white 3000 K for calm rooms, prismatic diffuser with UGR ≤ 19.
Dimmable via DALI or push button, flicker-free, suitable for emergency lighting.
White aluminium profile blends into light ceilings.

Applications

Meeting and conference rooms
Medical practices and reception areas
Care and lounge areas
Individual workstations and alcoves

Installation and accessories

Ceiling mounted, 3.1 kg.
Between start and end luminaire, via connector.
Accessories: DALI MCU rotary dimmer, presence detector IR-Quattro-HD-DALI with AP-Box, RC 5 DALI remote control.

Technical data

Manufacturer part no.	114361000
Order number	00807938
EAN	4013330073879
Connected load	220-240 V, 50 Hz, 60 Hz
Work equipment	Adjustable electronic ballast, digital DALI
Power consumption	approx. 10 W
Standby	approx. 0.2 W
Luminous flux	approx. 1000 lm
Luminous efficiency	approx. 100 lm/W
Light type/-color	Warm white
Colour temperature	approx. 3000 K
Color rendering index	CRI ≥ 80
Light distribution	Direct, approx. 100 %
Glare control	Prism aperture
Light source	LED
Life expectancy LED	L90B50, 50,000 h
Chromaticity tolerance LED	< 3 SDCM
At-risk group	RG0/1
Luminance (L65)	≤ 3000 cd/m²
UGR class (4H 8H, EN 12464-1)	≤ 19
System of protection/Class	IP 40, I
Technology	Continuously dimmable
Operation	External
Housing	Sectional aluminium, White
Light source cover	Acrylic (PMMA), Clear
Mains lead	Connector, Middle luminaire
Design	mounted version
Fastening	Ceiling mounted
Weight without/incl. packaging	3.1 kg / approx. 4.1 kg
Dimensions (dimensional drawing)	L = 842 mm
Packaging dimensions	1000 mm x approx. 190 mm x 120 mm
Power factor	approx. 0.97
Special features	Flicker-free, DALI Load 1x, Suitable as emergency lighting, Through-wired, up to 18 m on one mains connection, Mechanical and electrical connection of the individual modules without tools, TouchDIM - dimming via standard switch
Weight	4.1 kg
Manufacturer	Waldmann
Manufacturer Nr.	114361000-00807938
HS-Code	94051140
GPSR manufacturer information	WALDMANN Lichttechnik Peter-Henlein-Straße 5 DE-78056 Villingen-Schwenningen
Condition of article	New
Article authenticity	Original product
Country of Manufacture	Germany
Sales unit	1 Stück
Colour	White
Farbe	Weiß
Control and dimming	DALI dimmable
Luminous flux (lumen)	1000 lm
Power (W)	10 W
Colour rendering (Ra)	Ra 80
Mounting type	Surface-mounted
Operating voltage	220-240 V
Series	DOTOO.line
Protection class (IP)	IP40
