LED recessed luminaire DOTOO.line DLE 3000/840/D, 2750 lm, 4000 K, 2256 mm, DALI

Images are examples, some edited with AI. The technical data are authoritative. AI notice

LED recessed luminaire DOTOO.line DLE 3000/840/D, 2750 lm, 4000 K, 2256 mm, DALI - Waldmann 114407000-00808225

Name: LED recessed luminaire DOTOO.line DLE 3000/840/D, 2750 lm, 4000 K, 2256 mm, DALI - Waldmann 114407000-00808225
Brand: Waldmann
SKU: WAL-114407000-00808225
Price: 702.28 EUR
Availability: InStock

Waldmann ✓ Original product Brand new Made in Germany

LED recessed luminaire DOTOO.line DLE 3000/840/D with approx. 2750 lm at 26 W, 4000 K and a length of 2256 mm. DALI dimmable, flicker-free and suitable for emergency lighting, prismatic cover with UGR ≤ 19. For offices, screen work and administration.

Net

€702.28

excl. VAT

Item WAL-114407000-00808225

Manufacturer no. 114407000-00808225

Question about this item

Datasheet (PDF) User manual 6 documents, all under Downloads

Specialist dealer since 2009
Invoice payment for regular customers
Worldwide shipping
Technical questions clarified with the manufacturer

Description

Approx. 2750 lm at 26 W over a length of L = 2256 mm: the DOTOO.line DLE 3000/840/D in neutral white 4000 K illuminates office zones, rows of workstations and laboratory areas with just a few light lines. Luminous efficacy is approx. 105 lm/W.

Benefits

Neutral white 4000 K, CRI ≥ 80, for focused screen work
Flicker-free and suitable for emergency lighting
LED life L90B50 50,000 h, colour tolerance < 3 SDCM
Easy maintenance thanks to readily accessible ballasts
DALI ballast (DALI load 1x), continuously dimmable, alternatively via TouchDIM using a standard push button
Prismatic cover, L65 ≤ 3000 cd/m², UGR ≤ 19: even, low-glare light at the workstation

Applications

Laboratories and medical practices
Office and display screen workstations
Administration and clerical work
Meeting rooms

Installation and accessories

Recessed ceiling mounting with fastening brackets, mains connection via connection terminal, external switching
Matching: DALI MCU digital rotary dimmer, IR-Quattro-HD-DALI presence detector with surface-mounting adaptor, RC 5 DALI remote control for the presence detector

Technical data

Manufacturer part no.	114407000-00808225
Order no.	00808225
EAN	4013330079741
Connected load	220-240 V, 50 Hz, 60 Hz
Control gear	Adjustable electronic ballast, digital DALI
Power consumption	approx. 26 W
Standby	≤ 0.2 W
Luminous flux	approx. 2750 lm
Luminous efficiency	approx. 105 lm/W
Light colour	Neutral white
Colour temperature	approx. 4000 K
Colour rendering index	CRI ≥ 80
Light distribution	Direct, approx. 100 %
Beam angle	86 °
Glare control	Prism aperture
Life expectancy LED	L90B50 50,000 h
Chromaticity tolerance LED	< 3 SDCM
At-risk group	RG0/1
Luminance (L65)	≤ 3000 cd/m²
UGR class (4H 8H, EN 12464-1)	≤ 19
System of protection/Class	IP 40, I
Technology	Continuously dimmable
Operation	External
Housing	Sectional aluminium, White
Light source cover	Acrylic (PMMA), Clear
Mains lead	Connection terminal
Design	Recessed version
Fastening	Fastening bracket
Weight without/incl. packaging	7.3 kg / approx. 7.8 kg
Dimensions (dimensional drawing)	L = 2256 mm
Power factor	approx. 0.97
Special features	Flicker-free, DALI Load 1x, Suitable as emergency lighting, TouchDIM - dimming via standard switch
Weight	7.8 kg
Manufacturer	Waldmann
Manufacturer Nr.	114407000-00808225
HS-Code	94051140
GPSR manufacturer information	WALDMANN Lichttechnik Peter-Henlein-Straße 5 DE-78056 Villingen-Schwenningen
Condition of article	New
Article authenticity	Original product
Country of Manufacture	Germany
Sales unit	1 Stück
Colour	White
Farbe	Weiß
Control and dimming	DALI dimmable
Luminous flux (lumen)	2750 lm
Power (W)	26 W
Colour rendering (Ra)	Ra 80
Mounting type	Recessed
Operating voltage	220-240 V
Series	DOTOO.line
Protection class (IP)	IP40
