Ceiling sensor KIRK KIR DT8/VTL/WS/PSP AN/BT/AB, DALI DT8, VTL dynamic white, surface-mounted - Waldmann 114420000-00810031

Planning office space around how it is really used takes data from the room itself. The KIRK KIR DT8/VTL/WS/PSP AN/BT/AB controls lighting by occupancy and daylight and also measures noise, air quality and temperature, drawing approx. 3 W. This variant combines DALI DT8 with VTL dynamic white in a surface-mounted housing.

Benefits

• DALI DT8: device type 8 control gear receives dimming level and colour temperature over the bus.
• VTL with daylight simulation: dynamic white between warm white and daylight.
• DALI supply on: powers up to 10 DALI devices, small groups need no bus power supply.
• PIR movement and daylight sensor for approx. 16 m²: light only when needed and only as much as needed.
• Measures noise, air quality (VOC) and temperature, LEDs on the sensor show the values.
• Bluetooth for wireless switches and app, optional LTX Cloud via the LTX Mesh-Net to analyse space use.

Applications

• Offices and VDU workstations
• Bookable workstations and desk-sharing zones
• Meeting rooms with an eye on noise and air quality
• Interior rooms with little daylight
• Retrofitting small luminaire groups

Installation and accessories

• Surface-mounted version for ceilings without a void, mounting height 2.5-3.5 m
• Connector, installation in standard junction boxes, an old sensor is replaced directly
• Accessory: surface-mounted housing (surface mount adapter)
