LED recessed panel DOTOO.fit DFE 4000/840, 4100 lm, 4000 K, 1200 x 300 mm, 220-240 V

Images are examples, some edited with AI. The technical data are authoritative. AI notice

LED recessed panel DOTOO.fit DFE 4000/840, 4100 lm, 4000 K, 1200 x 300 mm, 220-240 V - Waldmann 114546000-00815305

Name: LED recessed panel DOTOO.fit DFE 4000/840, 4100 lm, 4000 K, 1200 x 300 mm, 220-240 V - Waldmann 114546000-00815305
Brand: Waldmann
SKU: WAL-114546000-00815305
Price: 145.35 EUR
Availability: InStock

Waldmann ✓ Original product Brand new Made in Germany

DOTOO.fit DFE 4000/840 LED recessed panel for 1200 x 300 mm grid ceilings with approx. 4100 lm and 4000 K. Built-in 220-240 V power supply, switchable, no separate driver needed. For offices and administration.

Net

€145.35

excl. VAT

Item WAL-114546000-00815305

Manufacturer no. 114546000-00815305

Question about this item

Datasheet (PDF) User manual 6 documents, all under Downloads

Specialist dealer since 2009
Invoice payment for regular customers
Worldwide shipping
Technical questions clarified with the manufacturer

Description

For linear grid ceilings with a 1200 x 300 mm module without a central low-voltage supply, the DOTOO.fit DFE 4000/840 with built-in power supply unit is the direct route: it connects to 220-240 V and is switched externally. With approx. 4100 lm at approx. 30 W (136 lm/W) and an installation depth of 40 mm, it lights work surfaces evenly and with low glare.

Benefits

Integrated power supply unit: 220-240 V, 50/60 Hz, protection class II, 5-pole connector (approx. 0.8 m)
Approx. 136 lm/W luminous efficiency at approx. 30 W power consumption
Strain relief with through-wiring simplifies cabling of complete luminaire rows
CRI ≥ 80 with neutral white 4000 K for focused work

Applications

Offices and administration
Corridors and ancillary rooms in office buildings
Elongated zones and corridors in office buildings
Screen workstations

Installation and accessories

Lay-in installation in grid ceilings with a 1200 x 300 mm module
Wire rope suspension (2x), 2000 mm, for suspended installation
Mains connection via 5-pole connector, lead approx. 0.8 m

Technical data

Manufacturer part no.	114546000-00815305
Order number	00815305
EAN	4013330187484
Connected load	220-240 V, 50 Hz, 60 Hz
Work equipment	Power supply unit
Secondary voltage	24 V
Power consumption	approx. 30 W
Sec. power consumption	approx. 28 W
Luminous flux	approx. 4100 lm
Luminous efficiency	approx. 136 lm/W
Light type/-color	Neutral white
Colour temperature	approx. 4000 K
Color rendering index	CRI ≥ 80
Light distribution	Direct, approx. 100 %
Beam angle	80°
Glare control	Prism aperture
Light source	LED
Life expectancy LED	L80B50 75,000 h
Chromaticity tolerance LED	< 3 SDCM
At-risk group	RG0/1
Luminance (L65)	≤ 3000 cd/m²
UGR class (4H 8H, EN 12464-1)	≤ 19
System of protection/Class	IP40 / IP20, protection class II
Technology	Switchable
Operation	External
Housing	Sectional aluminium, White
Mains lead	approx. 0.8 m, Connector, 5-pole
Design	Integrated version
Installation dimensions	approx. 1200 x 300 x 40 mm
Maximum ambient temperature	25 °C
Weight without/incl. packaging	2.9 kg
Special features	Flicker-free, Direct light component with edge light and light-guide technology for homogenous light exit, System dimension 1200 x 300 mm, Strain relief with the possibility of through-wiring
Weight	2.9 kg
Manufacturer	Waldmann
Manufacturer Nr.	114546000-00815305
HS-Code	94051140
GPSR manufacturer information	WALDMANN Lichttechnik Peter-Henlein-Straße 5 DE-78056 Villingen-Schwenningen
Condition of article	New
Article authenticity	Original product
Country of Manufacture	Germany
Sales unit	1 Stück
Colour	White
Farbe	Weiß
Luminous flux (lumen)	4100 lm
Power (W)	30 W
Colour rendering (Ra)	Ra 80
Mounting type	Recessed
Operating voltage	220-240 V
Series	DOTOO.fit
Protection class (IP)	IP40
