LED continuous row luminaire TAUREO TRG 9000/840/MB/DA/1686/7/WS, 9000 lm, 75° medium beam, DALI

Images are examples, some edited with AI. The technical data are authoritative. AI notice

LED continuous row luminaire TAUREO TRG 9000/840/MB/DA/1686/7/WS, 9000 lm, 75° medium beam, DALI - Waldmann 227229079-00817683

Name: LED continuous row luminaire TAUREO TRG 9000/840/MB/DA/1686/7/WS, 9000 lm, 75° medium beam, DALI - Waldmann 227229079-00817683
Brand: Waldmann
SKU: WAL-227229079-00817683
Price: 209.10 EUR
Availability: InStock

Waldmann ✓ Original product Brand new Made in Germany

Gear tray for the TAUREO continuous row system with 9000 lm at 56.5 W, i.e. 159 lm/W, and a 75° beam angle (medium beam). Intended for ceiling lighting in halls, production and warehouses.

Net

€209.10

excl. VAT

Item WAL-227229079-00817683

Manufacturer no. 227229079-00817683

Question about this item

Datasheet (PDF) User manual 6 documents, all under Downloads

Specialist dealer since 2009
Invoice payment for regular customers
Worldwide shipping
Technical questions clarified with the manufacturer

Description

A hall should be evenly bright and use little energy in operation. The TAUREO TRG 9000 reaches 159 lm/W and delivers 9000 lm at 56.5 W, dimmable via DALI.

Benefits

9000 lm at 56.5 W, luminous efficiency 159 lm/W
Medium 75° optics balance the light between area and height.
Digitally dimmable DALI ballast for daylight and presence control via the building management system
Neutral white 4000 K, CRI ≥ 80, chromaticity tolerance < 3 SDCM, LED life L80B50 100,000 h
Operation at -20 to 45 °C ambient temperature

Applications

Production and assembly halls
Warehousing and logistics
Workshops and manufacturing areas

Installation and accessories

Ceiling mounted in the TAUREO continuous row system
TAUREO TRT mounting rail available separately

Technical data

Manufacturer item no.	227229079-00817683
Order number	00817683
EAN	4013330200657
Connected load	220-240 V, AC, 50 Hz, 60 Hz, IK02
Work equipment	Adjustable electronic ballast, digital DALI
Power consumption	approx. 56.5 W
Luminous flux	approx. 9000 lm
Luminous efficiency	approx. 159 lm/W
Light type/-color	Neutral white
Colour temperature	approx. 4000 K
Color rendering index	CRI ≥ 80
Light distribution	Direct, approx. 100 %
Beam angle	75 °
Glare control	Optics
Light source	LED
Life expectancy LED	L80B50 100,000 h
Chromaticity tolerance LED	< 3 SDCM
EPREL number of lightsources	769336, 769343
At-risk group	RG0/1
Luminance (L65)	≤ 5000 cd/m²
UGR class (4H 8H, EN 12464-1)	≤ 19
System of protection/Class	IP 40, I
Technology	Continuously dimmable
Housing	Sheet metal, Painted, White
Light source cover	Acrylic (PMMA), Clear
Fastening	Ceiling mounted
Ambient temperature min./max	-20 °C / 45 °C
Weight without/incl. packaging	2.4 kg / approx. 2.9 kg
Packaging dimensions	1770 mm x approx. 222 mm x 95 mm
Special features	Medium Beam
Weight	2.9 kg
Manufacturer	Waldmann
Manufacturer Nr.	227229079-00817683
HS-Code	94051140
GPSR manufacturer information	WALDMANN Lichttechnik Peter-Henlein-Straße 5 DE-78056 Villingen-Schwenningen
Condition of article	New
Article authenticity	Original product
Country of Manufacture	Germany
Sales unit	1 Stück
Colour	White
Farbe	Weiß
Control and dimming	DALI dimmable
Luminous flux (lumen)	9000 lm
Power (W)	56,5 W
Colour rendering (Ra)	Ra 80
Operating voltage	220-240 V
Series	TAUREO
Protection class (IP)	IP40
