LED continuous-row gear tray TAUREO TRG 9000/840/NB/DA/1686/7/WS, 9000 lm, 35°

Images are examples, some edited with AI. The technical data are authoritative. AI notice

LED continuous-row gear tray TAUREO TRG 9000/840/NB/DA/1686/7/WS, 9000 lm, 35° - Waldmann 227229089-00817684

Name: LED continuous-row gear tray TAUREO TRG 9000/840/NB/DA/1686/7/WS, 9000 lm, 35° - Waldmann 227229089-00817684
Brand: Waldmann
SKU: WAL-227229089-00817684
Price: 209.10 EUR
Availability: InStock

Waldmann ✓ Original product Brand new Made in Germany

Gear tray for the TAUREO continuous-row system with approx. 9000 lm, 56.5 W and a 35° narrow beam optic. DALI dimmable, 4000 K, IP40. For high-bay warehouses and tall production halls.

Net

€209.10

excl. VAT

Item WAL-227229089-00817684

Manufacturer no. 227229089-00817684

Question about this item

Datasheet (PDF) User manual 6 documents, all under Downloads

Specialist dealer since 2009
Invoice payment for regular customers
Worldwide shipping
Technical questions clarified with the manufacturer

Description

The TAUREO TRG 9000/840/NB/DA/1686/7/WS gear tray equips continuous rows in industrial halls with approx. 9000 lm at 56.5 W, which corresponds to approx. 159 lm/W. The 35° beam angle concentrates the light downwards, delivering it to the working level even from high mounting positions or into narrow aisles.

Benefits

Luminous flux approx. 9000 lm: a mid-range step at 56.5 W that covers typical production and storage halls with few rows
Luminous efficiency of approx. 159 lm/W lowers energy use in continuous operation
DALI ballast, continuously dimmable, for lighting management and daylight control via the bus
Neutral white 4000 K, CRI ≥ 80 and chromaticity tolerance < 3 SDCM for a uniform appearance along the row
LED life of L80B50 100,000 h reduces maintenance work at height

Applications

High-bay warehouses and narrow racking aisles
Tall production halls with high mounting heights
Targeted lighting of machine lines and conveyor sections

Installation and accessories

Gear tray for insertion into the TAUREO TRT mounting rail, type code 1686/7 (7-pole, 1686 mm)
Ceiling mounted, housing in white painted sheet metal, clear acrylic (PMMA) cover
Mains connection 220-240 V AC, 50/60 Hz, IP40, protection class I, weight approx. 2.4 kg without packaging

Technical data

Manufacturer item no.	227229089-00817684
Order number	00817684
EAN	4013330200664
Connected load	220-240 V, AC, 50 Hz, 60 Hz, IK02
Work equipment	Adjustable electronic ballast, digital DALI
Power consumption	approx. 56.5 W
Luminous flux	approx. 9000 lm
Luminous efficiency	approx. 159 lm/W
Light type/-color	Neutral white
Colour temperature	approx. 4000 K
Color rendering index	CRI ≥ 80
Light distribution	Direct, approx. 100 %
Beam angle	35°
Glare control	Optics
Light source	LED
Life expectancy LED	L80B50 100.000 h
Chromaticity tolerance LED	< 3 SDCM
EPREL number of lightsources	769336, 769343
At-risk group	RG0/1
Luminance (L65)	≤ 18,000 cd/m²
UGR class (4H 8H, EN 12464-1)	≤ 25
System of protection/Class	IP 40, I
Technology	Continuously dimmable
Housing	Sheet metal, Painted, White
Light source cover	Acrylic (PMMA), Clear
Fastening	Ceiling mounted
Ambient temperature min./max	-20 °C, 45 °C
Weight without/incl. packaging	2.4, approx. 2.9 kg
Packaging dimensions	1770 mm, approx. 222 mm, 95 mm
Special features	Narrow Beam
Weight	2.9 kg
Manufacturer	Waldmann
Manufacturer Nr.	227229089-00817684
HS-Code	94051140
GPSR manufacturer information	WALDMANN Lichttechnik Peter-Henlein-Straße 5 DE-78056 Villingen-Schwenningen
Condition of article	New
Article authenticity	Original product
Country of Manufacture	Germany
Sales unit	1 Stück
Colour	White
Farbe	Weiß
Control and dimming	DALI dimmable
Luminous flux (lumen)	9000 lm
Power (W)	56,5 W
Colour rendering (Ra)	Ra 80
Operating voltage	220-240 V
Series	TAUREO
Protection class (IP)	IP40
