Continuous-row mounting rail TAUREO TRT 5058/7/WS, 5058 mm, 7-pole, white

Images are examples, some edited with AI. The technical data are authoritative. AI notice

Continuous-row mounting rail TAUREO TRT 5058/7/WS, 5058 mm, 7-pole, white - Waldmann 227230039-00817724

Name: Continuous-row mounting rail TAUREO TRT 5058/7/WS, 5058 mm, 7-pole, white - Waldmann 227230039-00817724
Brand: Waldmann
SKU: WAL-227230039-00817724
Price: 147.05 EUR
Availability: InStock

Waldmann ✓ Original product Brand new Made in Germany

Mounting rail for the TAUREO continuous-row system, 5058 mm long, 7-pole wiring, white sheet metal, IP40. It is fixed to the ceiling and receives the TAUREO gear trays. For light lines in production, warehousing and workshops.

Net

€147.05

excl. VAT

Item WAL-227230039-00817724

Manufacturer no. 227230039-00817724

Question about this item

Datasheet (PDF) User manual 6 documents, all under Downloads

Specialist dealer since 2009
Invoice payment for regular customers
Worldwide shipping
Technical questions clarified with the manufacturer

Description

The TAUREO TRT 5058/7/WS mounting rail forms the backbone of a light line: it is fixed to the ceiling, carries the wiring and receives the TAUREO gear trays. At 5058 mm it equals three 1686 mm base lengths and suits long rows with few suspension points and joints.

Benefits

Length 5058 mm (5.06 m) for planning row lengths on a 1686 mm grid
7-pole wiring: carries mains and control line for the DALI gear trays along the row
White painted sheet metal housing, IP40, protection class I
No control gear of its own, luminous flux and optic are set by the inserted gear tray

Applications

Continuous rows in production and assembly halls
Warehousing, logistics and order picking
Workshops and electronics production with long rows of workstations

Installation and accessories

Surface-mounted version for ceiling installation, fixing material available separately
Mains connection 220-240 V, 50/60 Hz
Receives TAUREO TRG gear trays, weight approx. 7.83 kg without packaging

Technical data

Manufacturer item no.	227230039-00817724
Order number	00817724
EAN	4013330200534
Connected load	220-240 V, 50 Hz, 60 Hz
Work equipment	Without
System of protection/Class	IP 40, I
Housing	Sheet metal, Painted, White
Design	Mounted version
Fastening	Ceiling mounted, Available separately
Weight without/incl. packaging	7.83, approx. 7.9 kg
Dimensions (dimensional drawing)	L=5058 mm
Packaging dimensions	5118 mm, approx. 130 mm, 60 mm
Special features	7-pole
Weight	7.9 kg
Manufacturer	Waldmann
Manufacturer Nr.	227230039-00817724
HS-Code	94051140
GPSR manufacturer information	WALDMANN Lichttechnik Peter-Henlein-Straße 5 DE-78056 Villingen-Schwenningen
Condition of article	New
Article authenticity	Original product
Country of Manufacture	Germany
Sales unit	1 Stück
Colour	White
Farbe	Weiß
Overall length [mm]	5058
Operating voltage	220-240 V
Series	TAUREO
Protection class (IP)	IP40
