Continuous-row mounting rail TAUREO TRT 3372/11/WS, 3372 mm, 11-pole, white - Waldmann 227230059-00817726

The TAUREO TRT 3372/11/WS mounting rail forms the backbone of a light line: it is fixed to the ceiling, carries the wiring and receives the TAUREO gear trays. At 3372 mm it equals two 1686 mm base lengths and halves the number of joints compared with short rails.

Benefits

• Length 3372 mm (3.37 m) for planning row lengths on a 1686 mm grid
• 11-pole wiring: provides additional conductors, for example for separate circuits or several switching groups in one row
• White painted sheet metal housing, IP40, protection class I
• No control gear of its own, luminous flux and optic are set by the inserted gear tray

Applications

• Continuous rows in production and assembly halls
• Warehousing, logistics and order picking
• Workshops and electronics production with long rows of workstations

Installation and accessories

• Surface-mounted version for ceiling installation, fixing material available separately
• Mains connection 220-240 V, 50/60 Hz
• Receives TAUREO TRG gear trays, weight approx. 5.7 kg without packaging
