Interchangeable Blade TORX MagicSpring for easyTorque Key T9 x 175 mm max. 2.5 Nm - Wiha 27814

The 28595R TORX T9 interchangeable blade at 175 mm overall length with its slim 4 mm hex shank delivers reproducible tightening values up to 2.5 Nm for T9 joints. The MagicSpring feature holds the screw by form fit using a spring steel ring, with no magnetic field that could affect sensitive components.

Benefits

• MagicSpring retains T9 screws without magnets in any orientation
• Slim blade diameter, 4 mm, for hard-to-reach installation points
• Chrome-vanadium-molybdenum steel, through-hardened and zinc-plated, for long service life
• Dark green colour coding for quick visual identification
• Compatible with Wiha easyTorque Key torque tools

Technical data

• TORX: T9
• Max. torque value: 2.5 Nm
• Hex blade diameter: 4 mm
• Overall length: 175 mm
• Visible blade length: 42 mm
• Material: chrome-vanadium-molybdenum steel, through-hardened, zinc-plated

Applications

For controlled tightening of T9 screws to a pre-set torque up to 2.5 Nm in combination with the Wiha easyTorque Key. Used in precision mechanics, electronics and wherever reproducible tightening values and process safety are required. Made in Germany (HS 82079030).
