Interchangeable Blade TORX PLUS® MagicSpring® 9IP, 175 mm, max. 3.0 Nm - Wiha 29556

The Wiha 28596R interchangeable blade in size 9IP is designed for use with Wiha torque screwdrivers with long handle and MagicSpring® system. The blade is made from high-quality chrome-vanadium-molybdenum steel, through-hardened and zinc-plated. The very slim blade diameter of 4 mm gives access to screws in confined positions.

Benefits

• TORX PLUS® 9IP profile for high torque transfer with low edge stress
• Slim blade diameter of 4 mm for restricted installation situations
• CrVMo steel, through-hardened - long service life
• Light-green colour coding for quick size identification
• Max. torque 3.0 Nm for controlled fastening

Technical data

• TORX PLUS®: 9IP
• Max. torque value: 3.0 Nm
• Overall length: 175 mm
• Visible blade length: 42 mm
• Hex blade diameter: 4 mm
• Product dimensions: 175 x 8 x 8 mm (L x W x D)
• Material: Chrome-vanadium-molybdenum steel, hardened, zinc-plated

Applications

For controlled fastening at a pre-set torque using Wiha torque screwdrivers with long handle and MagicSpring® chuck. Suitable for electronics, precision mechanics, and any area requiring defined tightening torques.

Made in Germany. HS code 82079030.
