Automatic Crimp Tool for Wire-End Sleeves 0.08-16 mm², 360° Rotating Head - Wiha 45223

The Wiha crimp tool 45223 addresses one of the most common challenges in wire-end sleeve processing: crimping in hard-to-reach locations. The crimping head rotates 360° and locks in 45° steps, enabling front and side access. The double-sided crimping opening accepts wire-end sleeves up to 18 mm in length in a single operation. The automatic crimping function self-adjusts to the respective cross-section and ensures the process is fully completed.

Benefits

• Crimping range 0.08-16 mm² for single sleeves and 2 x 0.25-2 x 10 mm² for twin sleeves
• 360° rotating crimping head with 45° detents for confined-space access
• Automatic crimping function - self-adjusting to the wire cross-section
• Emergency release for manual interruption at any time
• Ergonomic soft handles with anti-slip coating
• High-strength special steel, toggle joint mechanism for maximum force transmission

Technical data

• Cross section: 0.08-16 mm² (single) / 2 x 0.25-2 x 10 mm² (twin)
• AWG: 28-5
• Max. sleeve length: 18 mm
• Overall length: 193 mm
• Width: 24 mm, height: 62 mm
• Standards: DIN 46228, EN 50027

Applications

Suitable for processing wire-end sleeves with and without insulating collar to DIN 46228 and EN 50027, particularly in hard-to-access locations in control cabinets and cable ducts. Made in Germany.

Country of origin: Germany (DE). HS code: 82032000.
