Protective cup 20 x 26 mm with vacuum puller - JBC E2064
Protective cup 20 x 26 mm (rectangular) with integrated vacuum puller for JBC hot-air repair stations. Concentrates the hot air on the component and lifts it off after desoldering.
- Specialist dealer since 2009
- Invoice payment for regular customers
- Worldwide shipping
- Technical questions clarified with the manufacturer
Description
The protective cup with integrated vacuum puller concentrates the hot air on the target area of the board and protects the surrounding components from excess heat. After desoldering, the built-in puller picks up the component by suction and lifts it off. The 20 x 26 mm cup opening is matched to components of this size.
Benefits
- Inner size 20 x 26 mm (rectangular), matched to the component
- Concentrates the hot air precisely and protects neighbouring components from overheating
- Integrated vacuum puller lifts the component without mechanical load on the solder joints
- Designed for JBC hot-air repair stations
Applications
Repair and rework of SMD assemblies: targeted desoldering and lifting of ICs, QFP, BGA and other components on JBC hot-air stations while protecting the surrounding area.
Compatibility and scope of delivery
Scope of delivery: 1 protective cup with puller. Accessory for JBC hot-air repair stations. Other cup sizes of the same series are available for different component dimensions.
Origin: Spain. RoHS compliant, suitable for ESD-safe workstations to IEC 61340-5-1.
Technical data
| Item no. | WL13125 |
|---|---|
| Manufacturer item no. | E2064 |
| Model | 0932064 / E2064 |
| Manufacturer | JBC |
| Type | Protective cup with vacuum puller |
| Shape | rectangular |
| Dimensions (opening) | 20 x 26 mm |
| Dimensions with packaging (LxWxH) | 243 x 75 x 115 mm |
| Order unit | piece |
| Weight | 0.1 kg |
| Manufacturer Nr. | E2064 |
| HS-Code | 85159080900 |
| GPSR manufacturer information | JBC Soldering SL, Ramón y Cajal 3, ES-08750 Molins De Rei, www.jbctools.com |
| Condition of article | New |
| Article authenticity | Original product |
| Country of Manufacture | Spain |
| ESD version | ESD (antistatic) |
| Certification | IEC 61340-5-1 |
