Bulk roll of 10000 polyimide masking dots, 10 mm diameter, for masking wide openings and contact fields in series production. The brown-transparent film is rated to 300 °C at only 0.055 mm thickness. The pack size is designed for high throughput.
Solder masking dots polyimide 10 mm 10000 pieces bulk roll - PPI 7010/10.000
PPI
Original product
Net price (excl. VAT)
€409.89
Item
WL13508
Manufacturer no.
TAP 7010 / 10.000
Personal expert advice
Brand new
Specialist dealer since 2009
Original product
Worldwide shipping
Product data
Manufacturer no.TAP 7010 / 10.000
ConditionNew
Article
WL13508
Frequently Bought Together
-
This Item:
€409.89
-
Kapton polyimide solder masking tape 8 mm x 33 m, up to 300 °C - PPI 701/8 MM
€13.73
-
Kapton polyimide dots 10 mm, 2750 pieces per roll
€26.23
Total price
Large-area masking in series consumes material quickly. PPI TAP 7010 / 10.000 provides 10000 die-cut polyimide dots of 10 mm diameter per roll, temperature resistant to 300 °C and therefore designed for the complete wave soldering process.
Benefits
- 10000 dots per roll for high throughput and dispenser operation
- 10 mm diameter for wide openings, relay windows and contact fields
- Temperature resistant up to 300 °C for wave and selective soldering
- Brown-transparent polyimide film for visual control of the masked area
- Total thickness of 0.055 mm including adhesive for a flat, tight seal
Technical data
| Item number | WL13508 |
| Model | 110-10 / 10.000 |
| Manufacturer | PPI |
| Manufacturer item number | TAP 7010 / 10.000 |
| Order unit | Roll |
| Content unit | 10000 pieces |
| Diameter | 10 mm |
| Material | Polyimide |
| Film thickness | 0.055 mm including adhesive |
| Temperature resistance | up to 300 °C |
| Colour | brown-transparent |
| Weight | 0.1 kg |
Applications
Series masking of wide cut-outs and contact fields before wave soldering, covering relay openings and connector zones during coating, and protecting defined surfaces during cleaning and surface treatment.
Compatibility and scope of delivery
Suits all common wave soldering, selective soldering and coating processes as well as standard label dispensers. Delivery consists of one roll with 10000 masking dots of 10 mm diameter on a carrier liner.
| Manufacturer Nr. | TAP 7010 / 10.000 |
|---|---|
| Manufacturer | PPI |
| Weight | 0.100000 |
| GPSR manufacturer information | PPI GmbH Hommericherstraße 10-14 DE-51789 Lindlar www.ppiadhesiveproducts.com/de |
| Article authenticity | Original product |
| Condition of article | New |
| Position sensing | No |
