Kapton solder masking tape polyimide 9 mm x 33 m up to 300 °C - PPI 701/9 MM

Selective masking before wave soldering, reflow or conformal coating: this Kapton polyimide masking tape covers contact pads, connectors and test points while withstanding process temperatures up to 300 °C. Total thickness including adhesive is only 0.055 mm, so the tape lies flat even on fine pitch layouts.

Benefits

• Temperature resistant up to 300 °C, suitable for wave soldering and reflow processes
• Low total thickness of 0.055 mm including adhesive for precise edge coverage
• Brown-transparent film keeps the masked component visually accessible
• 9 mm width for narrow masking on pins and board edges
• 33 m roll as an economical consumable quantity in series production

Technical data

Applications

Masking gold contacts, connector strips, test points and holes before wave soldering. Also used for masking during conformal coating, for fixing wires inside assemblies and as heat resistant insulation during repair and rework.

Compatibility and scope of delivery

Delivered as one roll of polyimide tape, 9 mm wide and 33 m long. The tape belongs to the PPI 701 series, which is available in further widths from 9 to 28 mm so the right width can be combined for every masking task.
