Soldering tip conical 0.4 mm length 19 mm SSC 700 series - Metcal SSC-745A
Very fine conical soldering tip cartridge with 0.4 mm tip diameter and 19 mm tip length for the Metcal MFR-H6-SSC handpiece. The long slim body reaches joints in recessed areas and between tall components. Tip temperature is fixed at 412 °C.
- Specialist dealer since 2009
- Invoice payment for regular customers
- Worldwide shipping
- Technical questions clarified with the manufacturer
Description
Some joints sit deep between shields or heat sinks. The SSC-745A is a conical cartridge of the SSC 700 series with a tip diameter of just 0.4 mm and a length of 19 mm for exactly those cases.
Benefits
- Fine conical tip of 0.4 mm diameter for ultra fine pitch and wire repairs
- Long body with 19 mm tip length for access to deep areas
- Fixed tip temperature of 412 °C with no readjustment
- Heater inside the cartridge for short heat-up and fast changeover
- SSC 700 series for most standard applications
Applications
Ultra fine soldering on chip components and fine pitch ICs, repair wires and jumper links, and work inside tight enclosures or recessed board areas.
Compatibility and scope of delivery
The cartridge fits the MFR-H6-SSC handpiece and therefore works on the MFR-1160 and MFR-1161 soldering systems as well as on the SP200 station. Heater and temperature sensor sit inside the cartridge, so no calibration is required. Scope of delivery: one soldering tip cartridge.
Technical data
| Item number | WL13834 |
|---|---|
| Model | SSC-745A |
| Manufacturer | Metcal |
| Manufacturer item number | SSC-745A |
| Order unit | Piece |
| Product series | SSC 700 series |
| Tip length | 19 mm |
| Soldering tip diameter | 0.4 mm |
| Tip shape | Conical |
| Tip temperature | 412 °C |
| Suitable handpiece | MFR-H6-SSC |
| Weight | 0.1 kg |
| Weight | 0.100000 |
| Manufacturer Nr. | SSC-745A |
| GPSR manufacturer information | OK International Ltd Eagle Close, Chandlers Ford GB-SO53 4NF Hampshire www.metcal.com |
| Condition of article | New |
| Article authenticity | Original product |
| Tip diameter/width [mm] | 0.400000 |
| Soldering tip shape | konisch |
| Series | SSC |
