4H Jena OI 202.20.100. Stereo Zoom Microscope Head DSZT-44
Stereo Zoom Microscope Head DSZT-44. Eyepiece pair DSW 10x/23. Magnification 10x-44x. 45° oblique view.
- Specialist dealer since 2009
- Invoice payment for regular customers
- Worldwide shipping
- Technical questions clarified with the manufacturer
Description
The stereo zoom microscope head DSZT-44 from 4HJena impresses with 44x magnification and the possibility of adapting cameras, by using attachment optics an increase in working distance can be achieved.
Benefits
- Eyepiece pair DSW 10x/23
- Magnification 10x-44x
- 45° oblique view
- TV/photo output, switchable
- diopter compensation
- Adjustable interpupillary distance
A stereo microscope delivers an upright, laterally correct, three-dimensional image at a long working distance. Components can be handled, soldered, assembled and inspected under the microscope without tools and optics getting in each other's way. Depth perception makes it easier to assess solder joints, edges and surfaces.
Applications
- Visual inspection of PCBs, components and solder joints
- Assembly, rework and repair of small assemblies
- Quality assurance and incoming goods inspection
- Laboratory, precision mechanics and medical technology
Technical data
| Brand | 4H Jena |
|---|---|
| Zoom 4.4 | 1 |
| Manufacturer part number | OI 202.20.100 |
| (Optimal) working distance | 90 mm |
| Product type | Stereomicroscope head |
| Viewing angle | 45° |
| Type of lens | Eyepiece pair DSW 10x/23 |
| Camera zoom | 4,4:1 |
| Magnification | 10x-44x |
| Optimal working distance | 90 mm |
| Weight | 1.97 kg |
| Manufacturer | 4H Jena |
| Manufacturer Nr. | OI 202.20.100 |
| HS-Code | 90111000 |
| GPSR manufacturer information | -4H- JENA engineering GmbH, Mühlenstraße 126, DE-07745 Jena, www.4h-jena.de |
| Condition of article | New |
| Article authenticity | Original product |
| Country of Manufacture | China |
