4H Jena OI.202.25.200. Stereo Zoom Microscope Head SPZ-50
Stereo Zoom Microscope Head SPZ-50. Eyepiece pair DHW 10x/23. Magnification 6.7x to 50x. 45° oblique view.
- Specialist dealer since 2009
- Invoice payment for regular customers
- Worldwide shipping
- Technical questions clarified with the manufacturer
Description
The stereo zoom microscope head SPZ-50 from 4HJena with 50x magnification, by using attachment optics an increase of the working distance can be achieved.
Benefits
- Eyepiece pair DHW 10x/23
- Magnification 6.7x to 50x
- 45° oblique view
- Diopter compensation on both sides
- Adjustable interpupillary distance
- rubber eyecups
A stereo microscope delivers an upright, laterally correct, three-dimensional image at a long working distance. Components can be handled, soldered, assembled and inspected under the microscope without tools and optics getting in each other's way. Depth perception makes it easier to assess solder joints, edges and surfaces.
Applications
- Visual inspection of PCBs, components and solder joints
- Assembly, rework and repair of small assemblies
- Quality assurance and incoming goods inspection
- Laboratory, precision mechanics and medical technology
Technical data
| Brand | 4H Jena |
|---|---|
| Zoom 7.46 | 1 |
| Manufacturer part number | OI.202.25.200 |
| (Optimal) working distance | 108 mm |
| Product type | Stereomicroscope head |
| Viewing angle | 45° |
| Type of lens | Eyepiece pair DSW 10x/23 |
| Camera zoom | 7,46:1 |
| Magnification | 6.7x-50x |
| Optimal working distance | 108 mm |
| Weight | 5 kg |
| Manufacturer | 4H Jena |
| Manufacturer Nr. | OI.202.25.200 |
| HS-Code | 90119000 |
| GPSR manufacturer information | -4H- JENA engineering GmbH, Mühlenstraße 126, DE-07745 Jena, www.4h-jena.de |
| Condition of article | New |
| Article authenticity | Original product |
| Country of Manufacture | China |
