ESD extraction arm system DN50 2 joints, 445 mm, black - table mounting
Alsident 50-27-1-6. ESD extraction arm system DN50 2 joints, 445 mm, black - table mounting
ALSIDENT
Original product
Net price (excl. VAT)
€273.18
Item
WL20602
Manufacturer no.
50-27-1-6
Zertifiziert nach
ESD · IEC 61340-5-1
Personal expert advice
Brand new
Specialist dealer since 2009
Original product
Worldwide shipping
Product data
Manufacturer no.50-27-1-6
ConditionNew
Article
WL20602
Frequently Bought Together
-
This Item:
€273.18
-
Flange 160 mm polypropylene for extraction cabinet red - Alsident 4-160-13-4
€73.37
-
Alsident 75-3535-1-6. Extraction arm system DN75, 3 joints, 830 mm, black - table mounting
€584.74
Total price
The Alsident 50 system has tubes with a diameter of 50 mm and is suitable for air volumes of 45 -85 m3/h. As a result, the system is ideally suited for use in industries with smaller detection tasks, such as the electronics industry, laboratories, laser technology or even for specialist rooms in schools. The ESD-compliant extraction arm naturally complies with DIN EN 61340-5-1 and is earthed with 1MΩ resistor.
- All components RoHS compliant
- Maintenance-free O-rings
- Integrated throttle valve which is in open position from the air flow to ensure maximum flow through the unit
- Threaded rods, springs and thumbscrews in acid-resistant stainless steel (AISI 316L)
- Protective grille (accessory) to prevent foreign bodies from being sucked in
- Tested for use in ESD areas according to IEC 61340-5-1:2016
- The earthing cable has a 1 MΩ safety resistor
Product details
| item number | WL20602 |
| model | 50-27-1-6 |
| manufacturer | ALSIDENT |
| manufacturer item number | 50-27-1-6 |
| order unit | piece |
| colour | black |
| material | Tubes in chromated TCP aluminium, joints in conductive polypropylene |
| product series | Alsident System 50 AS |
| diameter of tube | 50 mm |
| air volume extraction arm | 45-85 m³/h |
| joint colour | black |
| range | 445 mm |
| number of joints | 2 |
| assembling | table mounting |
| ESD safe | yes |
| Certification | IEC 61340-5-1 |
|---|---|
| ESD version | ESD (antistatic) |
| Manufacturer Nr. | 50-27-1-6 |
| Manufacturer | Alsident |
| Weight | 0.100000 |
| Colour | Black |
| GPSR manufacturer information | Alsident system A/S Finlandsvej 10 DK-8450 Hammel www.alsident.com |
| Article authenticity | Original product |
| Condition of article | New |
| Position sensing | No |
