A ceiling mounted extraction arm needs a load bearing transition between the structural ceiling and the arm mount. This sheet steel base box is 500 mm long, has a side connection of 80 mm diameter and accepts extraction arms in nominal sizes DN 50, DN 63 and DN 75. All surfaces carry a TGIC powder coating, which increases durability in production and laboratory environments.
Base box ceiling mounting 500 mm side connection DN 50/63/75 - Alsident 2-500-80
ALSIDENT
Original product
Net price (excl. VAT)
€249.47
Item
WL20680
Manufacturer no.
2-500-80
Personal expert advice
Brand new
Specialist dealer since 2009
Original product
Worldwide shipping
Product data
Manufacturer no.2-500-80
ConditionNew
Article
WL20680
Frequently Bought Together
-
This Item:
€249.47
-
Alsident 75-9065-3-7. Extraction arm system DN75, 3 joints, 1550 mm, white - ceiling mounting, chemically resistant
€628.76
-
Extraction hood square DN75 420x320 mm transparent PETG - Alsident 1-754232-5
€155.78
Total price
When an extraction arm is mounted on the ceiling, the load has to be transferred safely and the air routed upwards. The base box 2-500-80 from Alsident does both: it bridges 500 mm to the mounting level and takes the connection out to the side with an 80 mm diameter.
Benefits
- Length of 500 mm bridges the distance between ceiling and extraction arm
- Side connection of 80 mm diameter for tight ceiling penetrations
- Very stable sheet steel construction for carrying ceiling mounted arms
- TGIC powder coating on all surfaces for increased durability
- Accepts extraction arms in nominal sizes DN 50, DN 63 and DN 75
Technical data
| Item number | WL20680 |
| Model | 2-500-80 |
| Manufacturer | Alsident |
| Manufacturer item number | 2-500-80 |
| Length | 500 mm |
| Diameter | 80 mm |
| Suitable for | DN 50, DN 63, DN 75 |
| Material | Sheet steel, TGIC powder coating on all surfaces |
| Colour | White |
| Mounting | Ceiling mounting |
| Connection | Side |
| Order unit | Piece |
| Weight | 0.1 kg |
Applications
Ceiling installation of extraction arms above soldering and repair benches, test cells, laboratory benches and dispensing stations. The side connection suits layouts where the ducting continues horizontally below the ceiling.
Compatibility and scope of delivery
For Alsident extraction arms of series 50, 63 and 75 in ceiling mounting. Scope of delivery: one base box 2-500-80 in coated sheet steel.
| Manufacturer Nr. | 2-500-80 |
|---|---|
| Manufacturer | Alsident |
| Weight | 0.100000 |
| GPSR manufacturer information | Alsident system A/S Finlandsvej 10 DK-8450 Hammel www.alsident.com |
| Article authenticity | Original product |
| Condition of article | New |
