Base box ceiling mounting 750 mm side connection DN 50/63/75 - Alsident 2-750-80

In rooms with greater clear height the ceiling mounted extraction arm has to start lower so that the hood reaches the workpiece. The base box 2-750-80 from Alsident bridges 750 mm for that purpose and at the same time provides the load bearing mount for the arm.

Benefits

• Length of 750 mm for high ceilings, the arm starts closer to the working level
• Side connection of 80 mm diameter for ducting that continues horizontally
• Very stable sheet steel construction as the load mount for ceiling arms
• TGIC powder coating on all surfaces for increased durability
• Accepts extraction arms in nominal sizes DN 50, DN 63 and DN 75

Technical data

Applications

Ceiling installation of extraction arms in halls and workshops with greater room height, above soldering and repair benches, test rigs, laboratory benches and bonding stations.

Compatibility and scope of delivery

For Alsident extraction arms of series 50, 63 and 75 in ceiling mounting. Scope of delivery: one base box 2-750-80 in coated sheet steel.
