At a soldering bench the capture point has to follow every hand movement, otherwise the fume drifts past the operator. The Alsident System 50 Flex offers 700 mm reach, one joint and a flexible hose that holds almost any position. Rated for 45-85 m³/h at a 50 mm tube diameter and made for mounting at the table edge.
Extraction arm System 50 Flex 700 mm table mounting black - Alsident 50-21-1-23-050
ALSIDENT
Original product
Net price (excl. VAT)
€302.53
Item
WL27443
Manufacturer no.
50-21-1-23-050
Personal expert advice
Brand new
Specialist dealer since 2009
Original product
Worldwide shipping
Product data
Manufacturer no.50-21-1-23-050
ConditionNew
Article
WL27443
Frequently Bought Together
-
This Item:
€302.53
-
Suction slot 100 mm DN50 red - Alsident 1-5010-4
€168.20
-
ESD extraction tip 250 mm conductive PP DN 75 black - Alsident 1-7525-6
€76.76
Total price
In manual soldering and laboratory work the emission point moves constantly, so the extraction arm must follow without effort and then stay put. The Alsident System 50 Flex 50-21-1-23-050 combines 700 mm reach with a flexible hose and is designed for an air volume of 45-85 m³/h at a 50 mm tube diameter.
Benefits
- Flexible hose widens the positioning range considerably compared with rigid tube arms
- Suction tip with a carefully formed cantilever increases capture efficiency
- Maintenance free O-rings and an integrated throttle valve that sits out of the air stream when open to secure maximum flow
- Threaded rods, springs and thumbscrews in acid resistant stainless steel AISI 316L, acid resistant POP rivets for long service life in aggressive environments
- All components RoHS compliant
Technical data
| Item number | WL27443 |
| Model | 50-21-1-23-050 |
| Manufacturer | Alsident |
| Manufacturer item number | 50-21-1-23-050 |
| Product series | Alsident System 50 Flex |
| Order unit | Piece |
| Colour | Black |
| Joint colour | Black |
| Reach | 700 mm |
| Number of joints | 1 |
| Tube diameter | 50 mm |
| Air volume extraction arm | 45-85 m³/h |
| Mounting | Table mounting |
| ESD safe | No |
| Material | Tubes and suction tip in anodised aluminium with 10μ layer thickness, plastic hose, polypropylene joints |
| Weight | 0.1 kg |
Applications
Source capture at manual soldering benches, rework and repair stations in the electronics industry and at laboratory workplaces where solder fume, solvent vapours or light aerosols have to be extracted close to the source.
Compatibility and scope of delivery
The arm belongs to Alsident System 50 and can be combined with hoods and slot hoods with a 50 mm connection. Supplied as a table version arm with one joint, the table bracket, fan and filter unit are ordered separately.
| Manufacturer Nr. | 50-21-1-23-050 |
|---|---|
| Manufacturer | Alsident |
| Weight | 0.100000 |
| Colour | Black |
| GPSR manufacturer information | Alsident system A/S Finlandsvej 10 DK-8450 Hammel www.alsident.com |
| Article authenticity | Original product |
| Condition of article | New |
