Alsident 50-3721-1-23-4. Extraction arm System 50 Flex 2 joints, 900 mm, red - table mounting
Extraction arm System 50 Flex 2 joints, 900 mm, red - table mounting. Increased possibilities of positioning due to the flexible hose.
Net
excl. VAT
€371.29
Item
AL-50-3721-1-23-4
Manufacturer no.
50-3721-1-23-4
- Specialist dealer since 2009
- Invoice payment for regular customers
- Worldwide shipping
- Technical questions clarified with the manufacturer
Description
The Alsident System 50 Flex is intended for an air volume of 45 - 85 m3/h and has a pipe diameter of 50 mm. The Flex system is particularly suitable for the electronics industry and laboratories.
Benefits
- Increased possibilities of positioning due to the flexible hose
- Suction tip with an elaborately processed cantilever to increase the efficiency of detection
- Maintenance-free O-rings
- Integrated throttle valve which is in open position from the air flow to ensure maximum flow through the unit
- Threaded rods, springs and thumbscrews in acid-resistant stainless steel (AISI 316L)
- Acid-resistant POP rivets for increased durability even when used in aggressive environments
Technical data
| Brand | Alsident |
|---|---|
| Manufacturer part number | 50-3721-1-23-4 |
| Colour | red |
| Material | Tubes and suction tip made of anodised aluminium - layer thickness 10μ, plastic hose, polypropylene joints |
| Product series | Alsident System 50 AL |
| Joint colour | red |
| Air volume extraction arm | 45-85 m³/h |
| Diameter of tube | 50 mm |
| Assembling | table mounting |
| Range | 900 mm |
| Number of joints | 2 |
| Device series | WSA-10LR, WSA-20LR, WSA-5LR |
| Weight | 1.52 kg |
| Manufacturer | Alsident |
| Manufacturer Nr. | 50-3721-1-23-4 |
| HS-Code | 84219990 |
| GPSR manufacturer information | Alsident system A/S Finlandsvej 10 DK-8450 Hammel www.alsident.com |
| Condition of article | New |
| Article authenticity | Original product |
| Country of Manufacture | Germany |
| Mounting type | Bench mounting |
| Compatible with | Alsident System 50 |
