ESD tote box IDP-STAT, dissipative, red, 400 x 300 x 170 mm, stackable - Warmbier 5311.R.14

Parts that must neither discharge quickly nor sit on an insulating surface belong in a container within the dissipative range. This tote box is made from Inherently Dissipative Polymer on a polypropylene base and measures 10^9 to 10^10 ohms, well above conductive black boxes.

Benefits

• Inherently Dissipative Polymer, the property is built into the plastic and does not depend on humidity or on a coating.
• Resistance range of 10^9 to 10^10 ohms limits discharge current more strongly than conductive material.
• Red colour tells dissipative boxes apart from conductive black ones at a glance in the store.
• External size 400 x 300 x 170 mm in the pallet module, internal size 355 x 255 x 165 mm suits inserts of the same format.
• Stackable, so storage units can be matched to the shelf height.
• Moulded ESD marking documents the box as EPA equipment.

Application

Inside the EPA the box stores and moves assemblies and small parts wherever a dissipative rather than a conductive container is specified. The red colour also helps to keep material flows apart, for example tested from untested goods or dissipative from conductive handling equipment.
