Combination filter cassette complete series 300 - ULT 02.1.420
The complete filter set K for LRA 300 solder fume extraction: expanded metal filter, M5/F7 mat set and H13A combination cassette in one order line. It renews the whole filter chain from coarse separation to the adsorption stage in a single service visit. Fits LRA 300 MD.14 K, MD.16 K and HD.13 K.
- Specialist dealer since 2009
- Invoice payment for regular customers
- Worldwide shipping
- Technical questions clarified with the manufacturer
Description
After extended operation it is not only the prefilter that is loaded but the HEPA and adsorption stages as well. This complete cassette set replaces every stage of filter set K at once and returns the extraction unit to its original condition with no guesswork left.
Benefits
- All three stages of filter set K in a single order line
- Includes expanded metal filter (ULT 4-00327), M5/F7 filter mat set (ULT 4-00266) and H13A combination cassette (ULT 4-00065)
- One maintenance slot instead of several partial changes
- No risk of mixing up filter layers during installation
- For the LRA 300 K solder fume units, 250 m³/h on MD.14 K and MD.16 K, 200 m³/h on HD.13 K
Applications
Annual servicing and overhaul of stationary solder fume extraction in electronics manufacturing, and commissioning of second-hand units where the condition of the individual filter stages is unknown.
Compatibility and scope of delivery
For the extraction units LRA 300 MD.14 K, LRA 300 MD.16 K and LRA 300 HD.13 K. Scope of delivery: expanded metal filter ULT 02.1.476, M5/F7 filter mat set ULT 02.1.474 and combination filter cassette H13A ULT 02.1.421. The H13A cassette on its own is also the replacement filter of the H13A post-filter module (ULT 0300.0-NFM021) on ASD 300 2Pa, ASD 300 TH and LAS 300 2Pa.
The HEPA element inside the H13A cassette corresponds to filter class H13 as defined in EN 1822.
Technical data
| Item number | WL26486 |
|---|---|
| Model | 02.1.420 |
| Manufacturer | ULT |
| Manufacturer item number | 02.1.420 |
| Order unit | Piece |
| Filter type | Complete filter set K |
| Individual elements | 02.1.476, 02.1.474, 02.1.421 |
| ULT replacement filter numbers | 4-00327, 4-00266, 4-00065 |
| Device series | LRA 300 MD.14 K, LRA 300 MD.16 K, LRA 300 HD.13 K |
| Weight | 0.100000 |
| Manufacturer Nr. | 02.1.420 |
| HS-Code | 84219990 |
| GPSR manufacturer information | ULT AG Am Göpelteich 1 DE-02708 Löbau www.ult.de |
| Condition of article | New |
| Article authenticity | Original product |
| Country of Manufacture | Germany |
| Norm | DIN EN 1822 |
| Filter class | H13 |
