Dismantling tool for round cables over 25 mm dia., cutting depth up to 5 mm, 150 mm - Knipex 16 40 150

Heavy round cables from 25 mm dia. are hard to open cleanly with a knife without nicking the cores underneath. The 16 40 150 dismantling tool works with a cutting depth adjustable up to 5.0 mm instead and removes all sheaths of standard cables under control.

Benefits

• For removing the sheath of round cables exceeding 25.0 mm dia., with no upper limit.
• Cutting depth adjustable up to 5.0 mm, so the core insulation stays intact.
• Suitable for circular and longitudinal cutting, one tool for the complete dismantling job.
• Replaceable blade that can be used on both sides and therefore lasts twice as long.
• Handle of glass fibre reinforced polyamide, robust and easy to guide at a total weight of 210 g.
• Compact overall length of 150 mm for work in the cable trench or in a tight distribution cabinet.

Technical data

Areas of use

Power supply and grid construction, connection of service and underground cables, switchgear manufacturing and industrial maintenance. Wherever the sheath of heavy round cables has to be opened, this tool replaces free-hand cutting with a knife.

Standards and conformity

According to the manufacturer the dismantling tool contains no substances of very high concern under REACH. The RoHS directive does not apply to this product.
