Soldering tip chisel 4 x 2.5 mm for T470 - JBC C470-035
Chisel, straight, 4 x 2.5 mm cartridge tip from the C470 series with integrated heater for the JBC T470. Working range 90-500 °C with fast thermal recovery for stable soldering.
- Specialist dealer since 2009
- Invoice payment for regular customers
- Worldwide shipping
- Technical questions clarified with the manufacturer
Description
C470 series cartridge tips for the JBC T470 heavy-duty soldering iron, driven by the HDE supply unit (formerly HD-4700) up to 500 °C. The robust design with integrated heating element delivers the high thermal output needed for large ground planes, thick leads and high heat-demand soldering.
Powerful chisel tip for use up to 500 °C with the HDE supply unit; designed for large ground planes and high heat demand.
Benefits
- Heating element integrated at the tip for heat-up and thermal recovery in seconds
- Geometry chisel, straight, 4 x 2.5 mm, designed for high heat-demand joints
- Working range 90-500 °C matched to JBC T470 technology
- Reinforced, durable tip plating for long service life
Applications
High heat-demand soldering such as large ground planes, thick leads and connectors.
Compatibility and scope of delivery
Fits the JBC T470 soldering iron. Scope of delivery: 1 cartridge tip (C470-035).
Manufactured by JBC (Spain). ESD safe per IEC 61340-5-1, RoHS compliant.
Technical data
| Item no. | WL27976 |
|---|---|
| Model | C470-035 |
| Manufacturer | JBC |
| Manufacturer item no. | C470035 |
| Tip series | C470 |
| Compatible iron / handpiece | T470 |
| Tip shape | chisel |
| Tip alignment | straight |
| Tip dimensions | 4 x 2.5 mm |
| Tip length | 10.5 mm |
| Total tip length | 120 mm |
| Integrated heater | yes |
| Working temperature | 90-500 °C |
| Dimensions with packaging (LxWxH) | 183 x 60 x 34 mm |
| Order unit | piece |
| Weight | 0.100000 |
| Manufacturer Nr. | C470035 |
| HS-Code | 85159080900 |
| GPSR manufacturer information | JBC Soldering SL, Ramón y Cajal 3, ES-08750 Molins De Rei, www.jbctools.com |
| Condition of article | New |
| Article authenticity | Original product |
| Country of Manufacture | Spain |
| ESD version | ESD (antistatic) |
| Certification | IEC 61340-5-1 |
| Tip diameter/width [mm] | 4.000000 |
| Soldering tip shape | meißelförmig |
| Series | C470 |
| Temperature range | 90-500 °C |
| Temperature (max.) | up to 500 °C |
