Soldering iron 50 W, blue handle, for C245 - JBC T245-PA
T245-PA soldering iron with 50 W and a blue handle for the C245 tip series. The lightweight iron with a 1.5 m cable works with all supply units from AD-2200 upwards and suits fast soldering in continuous use. It is supplied without a soldering tip.
- Specialist dealer since 2009
- Invoice payment for regular customers
- Worldwide shipping
- Technical questions clarified with the manufacturer
Description
The T245-PA soldering iron is a 50 W handpiece with a blue handle for the C245 tip series. The continuous heat flow of the C245 tips gives short heat-up times and stable working temperatures for general soldering work. It is supplied without a soldering tip.
Benefits
- 50 W nominal power at 24 V for fast soldering
- Blue handle for easy identification at the bench
- For the widely used C245 tip series
- Compatible with all supply units from AD-2200 upwards
- Flexible 1.5 m cable for freedom of movement
Applications
General soldering work, repair and production soldering on printed circuit boards and through-hole components.
Compatibility and scope of delivery
Fits the CD-S and CD-B soldering stations as well as the DI, DDE and DME control units and all supply units from AD-2200 upwards. Uses C245 series tips, suitable stand AD-SD. The iron is supplied without a soldering tip, order unit piece.
Suitable for use at ESD workstations in accordance with IEC 61340-5-1. Made in Spain.
Technical data
| Item no. | WL28066 |
|---|---|
| Manufacturer item no. | T245-PA |
| Manufacturer | JBC |
| Model | T245-PA |
| Handle type | soldering iron |
| Nominal power | 50 W |
| Voltage | 24 V |
| Suitable tips | C245 |
| Compatible soldering stations | CD-S, CD-B |
| Suitable control unit | DI, DDE, DME |
| Suitable stand | AD-SD |
| Suitable accessories | F3449 Fume Extractor, F3435 Fume Extractor, 0016057 Grips |
| Cable length | 1.5 m |
| Dimensions with packaging (LxWxH) | 235 mm x 40 mm x 40 mm |
| Order unit | piece |
| Weight | 0.1 kg |
| Manufacturer Nr. | T245-PA |
| GPSR manufacturer information | JBC Soldering SL, Ramón y Cajal 3, ES-08750 Molins De Rei, www.jbctools.com |
| Condition of article | New |
| Article authenticity | Original product |
| Colour | Blue |
| Certification | IEC 61340-5-1 |
| Power (W) | 150 W |
| Temperature range | 90-450 °C |
| Temperature (max.) | up to 450 °C |
