Diagonal cutter with narrow head for hard wire up to Ø 2.5 mm, comfort grips, 180 mm - Knipex 70 05 180

On a terminal strip or inside an equipment base the cut has to sit cleanly even when only a few millimetres of room are left. The diagonal cutter 70 05 180 has a narrow head style for that and precision cutting edges that sever hard wire up to Ø 2.5 mm.

Benefits

• Narrow head style for use in confined areas, so neighbouring components do not get in the way.
• Precision cutting edges for soft and hard wire, medium hard wire up to Ø 3.0 mm and hard wire up to Ø 2.5 mm.
• Clean cutting of thin copper wires right into the tips of the edges, which lets fine strands be trimmed flush.
• Cutting edges additionally induction hardened to a hardness of about 61 HRC, which extends the service life.
• Comfort grips made of three ergonomic components plus two KNIPEXtend interfaces for extensions.
• Chrome-plated head and body, tested to DIN ISO 5749, at a weight of 246 g.

Technical data

Areas of use

Electrical installation, control cabinet and control system building, assembly work and general maintenance. The cutter is designed as an all-rounder, wherever wire and stranded conductors are trimmed and access is tight.

Standards and conformity

For this model the manufacturer states DIN ISO 5749 for diagonal cutters. According to the manufacturer the tool contains no substances of very high concern under REACH. The RoHS directive does not apply.
