ESD earthing cable with protective cap 10 mm snap to 4 mm eyelet, 4.5 m, black - Warmbier 2250.790.2

This Warmbier earthing lead ties ESD table and floor mats to your common earthing point. The protective cap covers the snap connection, and the 4.5 m length gives generous reach.

Benefits

• Reliable drain of static charge from ESD mats
• Protective cap (43 mm diameter) covers the snap connection
• 1 MOhm safety resistor for a controlled discharge current

Technical data

• Connection: 10 mm snap to 4 mm eyelet
• Length: 4.5 m
• Protective cap diameter: 43 mm
• Typical leakage resistance: 1 MOhm safety resistor
• Colour: black
• Selling unit: 1 piece

Application

For grounding ESD bench mats and conductive floor coverings in electronics manufacturing, assembly and test.

Standards

Suitable for building EPA areas to IEC 61340-5-1 and EN 61340-5-1.
