A QFP with 52 or 80 leads has to reflow evenly on all sides or pads tear off. The H-Q14 nozzle with a 17.3 x 17.3 mm inner contour covers exactly this body size and delivers a closed hot air flow to every lead row. It is made for the Oki HCT-900 rework system.
Hot air desoldering nozzle QFP-52/80 17.3 x 17.3 mm for HCT-900 - Oki H-Q14
OKI
Original product
Net price (excl. VAT)
€115.00
Item
WL30761
Manufacturer no.
H-Q14
Personal expert advice
Brand new
Specialist dealer since 2009
Original product
Worldwide shipping
Product data
Manufacturer no.H-Q14
ConditionNew
Article
WL30761
Frequently Bought Together
-
This Item:
€115.00
-
Hot air nozzle square 32 x 32 mm for HCT-1000 - Oki HN-B3232
€409.12
-
Vacuum cup kit 4 pieces 3/16", 1/4", 5/16", 7/16" - Oki HCTA-VC-KIT
€14.35
Total price
QFP packages with 52 to 80 leads are sensitive to temperature differences between their sides during removal. The H-Q14 is the Oki HCT-900 desoldering nozzle for this body size and works with a 17.3 x 17.3 mm inner contour.
Benefits
- 17.3 x 17.3 mm inner dimension, matched to QFP-52 and QFP-80
- Closed air path for even reflow on all four sides
- Targeted heat input keeps board stress low
- Tool-free change on the HCT-900 handpiece
- Genuine Oki accessory for repeatable results
Technical data
| Item number | WL30761 |
| Model | H-Q14 |
| Manufacturer | OKI |
| Manufacturer item number | H-Q14 |
| Package | QFP-52 and QFP-80 |
| Inner dimension D | 17.3 x 17.3 mm |
| Weight | 0.1 kg |
Applications
SMD rework in repair and production, replacement of QFP-52 and QFP-80 devices, fault finding on assembled boards.
Compatibility and scope of delivery
Intended for the Oki HCT-900 hot air rework system. Scope of delivery: one H-Q14 desoldering nozzle.
| Manufacturer Nr. | H-Q14 |
|---|---|
| Manufacturer | Oki |
| Weight | 0.100000 |
| GPSR manufacturer information | OK International Ltd Eagle Close, Chandlers Ford GB-SO53 4NF Hampshire www.metcal.com |
| Article authenticity | Original product |
| Condition of article | New |
| Position sensing | No |
