Ceramic substrates and joints with a large thermal mass drain heat faster than a standard tip can replace it. This conical cartridge works at a 485 °C tip temperature and delivers that energy through a fine 0.5 mm point. For the MX-H1-AVA and MX-RM3E hand pieces on MX-500, MX-5000 and MX-5200.
Soldering tip conical 0.5 x 15.2 mm, 485 °C, STTC series - Metcal STTC-843
METCAL
Original product
Net price (excl. VAT)
€27.99
Item
WL31037
Manufacturer no.
STTC-843
Personal expert advice
Brand new
Specialist dealer since 2009
Original product
Worldwide shipping
Product data
Manufacturer no.STTC-843
ConditionNew
Article
WL31037
Frequently Bought Together
-
This Item:
€27.99
-
Soldering tip chisel 5 x 11.4 mm, 485 °C, STTC series - Metcal STTC-865
€32.67
-
Soldering tip chisel 30° 1.78 x 6 mm 302 °C STTC series - Metcal STTC-537
€27.99
Total price
Fine joints on ceramic or on large ground planes need a high working temperature combined with a small contact area. The Metcal STTC-843 is a conical soldering cartridge of the STTC series measuring 0.5 x 15.2 mm with a tip temperature of 485 °C.
Benefits
- Conical tip of 0.5 x 15.2 mm for closely spaced joints
- Tip temperature of 485 °C for ceramic substrates and large thermal mass
- Self regulating SmartHeat technology holds the temperature under load
- Runs on the MX-500, MX-5000 and MX-5200 systems
- Cartridge change without tools and without recalibration
Technical data
| Item no. | WL31037 |
| Model | STTC-843 |
| Manufacturer | Metcal |
| Manufacturer item no. | STTC-843 |
| Order unit | Piece |
| Product series | STTC series |
| Tip shape | Conical |
| Tip dimensions | 0.5 x 15.2 mm |
| Tip temperature | 485 °C |
| Compatible hand piece | MX-H1-AVA, MX-RM3E |
| Weight | 0.1 kg |
Applications
Hand soldering on ceramic substrates, joints on ground planes and thermal pads, rework on through hole and surface mounted parts as well as repair work in electronics production and service.
Compatibility and scope of delivery
The cartridge fits the MX-H1-AVA and MX-RM3E hand pieces and runs on the Metcal MX-500, MX-5000 and MX-5200 systems. Delivery covers one single cartridge without hand piece and without power unit.
| Manufacturer Nr. | STTC-843 |
|---|---|
| Manufacturer | Metcal |
| Weight | 0.100000 |
| GPSR manufacturer information | OK International Ltd Eagle Close, Chandlers Ford GB-SO53 4NF Hampshire www.metcal.com |
| Article authenticity | Original product |
| Condition of article | New |
| Series | STTC |
| Tip diameter/width [mm] | 0.500000 |
| Soldering tip shape | konisch |
