ESD extraction arm with flat nozzle 50 mm for WLA 250 - Donaldson Bofa A1020049

When a funnel above the assembly blocks the view, capturing from the side is the better option. Extraction arm A1020049 carries a flat, wide-slot nozzle for that purpose and connects to the WLA 250 extraction unit with a 50 mm port.

Benefits

• Flat wide-slot nozzle for lateral extraction across the board
• Clear view of the joint, the arm stays outside the working space
• 50 mm connection diameter matched to the WLA-250 device series
• Made of black, carbon-loaded, compressed polystyrene and therefore dissipative
• ESD-safe design for electronics workstations

Applications

Hand soldering benches with a microscope or magnifier lamp, board rework and repair, test stations, plus bonding and dispensing where there is no headroom for a hood above the assembly.

Compatibility and scope of delivery

Intended for the WLA 250 extraction unit with 50 mm connection. Scope of delivery: one extraction arm with flat nozzle, order unit piece.

The dissipative design suits workstations operated to IEC 61340-5-1.
