Large multi-pin packages tolerate no uneven heating, every lead has to reflow at the same time. The NZKT-2 set holds five nozzles for PLCC, QFP and BQFP packages: H-P20, H-P44, H-P84, H-Q1420 and H-Q2626. Designed for the HCT-900 hand-held convection tool.
Nozzle set 5 pieces for PLCC, QFP and BQFP, HCT-900 - Oki NZKT-2
OKI Original product
Net price (excl. VAT)
€428.08
Item WL35555
Manufacturer no. NZKT-2
Personal expert advice
Brand new Specialist dealer since 2009 Original product Worldwide shipping
Product data
Manufacturer no.NZKT-2
ConditionNew
Article
WL35555
Frequently Bought Together
- This Item: €428.08
- Desoldering nozzle 6.8 x 10.2 mm for SOIC 14 and 16 - Oki H-S16 €91.69
- Replacement heating element for HCT-900 hot air rework system - Oki HCT-HE-21 €71.03
Total price
PLCC, QFP and BQFP have leads on all four sides, so the nozzle must enclose the whole package and feed the hot air evenly to every row. The Oki NZKT-2 provides five nozzle sizes for exactly that, from the small 20-pin PLCC up to large quad flat packs.
Benefits
- Five nozzles in one set: H-P20, H-P44, H-P84, H-Q1420 and H-Q2626
- All-round openings feed the hot air evenly to every lead row
- Package-matched sizes protect neighbouring parts on densely populated boards
- Made for the HCT-900 hand-held convection tool
Technical data
| Item number | WL35555 |
| Model | NZKT-2 |
| Manufacturer | OKI |
| Manufacturer item number | NZKT-2 |
| Contents | 1x H-P20, 1x H-P44, 1x H-P84, 1x H-Q1420, 1x H-Q2626 |
| Matching system | HCT-900 |
| Weight | 0.1 kg |
Applications
Removing and placing PLCC, QFP and BQFP components in repair, rework, failure analysis and modification of sample boards.
Compatibility and scope of delivery
For the Oki HCT-900 hand-held convection tool. Delivery comprises the five nozzles H-P20, H-P44, H-P84, H-Q1420 and H-Q2626.
| Manufacturer Nr. | NZKT-2 |
|---|---|
| Manufacturer | Oki |
| Weight | 0.100000 |
| GPSR manufacturer information | OK International Ltd Eagle Close, Chandlers Ford GB-SO53 4NF Hampshire www.metcal.com |
| Article authenticity | Original product |
| Condition of article | New |
| Position sensing | No |
