Base box ceiling mounting 1250 mm DN 50/63/75 side connection - Alsident 2-1250-80

Mounting extraction arms under the ceiling costs headroom and looks unfinished when duct and fixings hang free. This 1250 mm Alsident base box combines mounting and duct routing in one folded sheet steel housing and provides a side connection of 80 mm diameter for extraction arms of the DN 50, 63 and 75 systems.

Benefits

• Very stable sheet steel construction, designed to carry complete extraction arms in ceiling installations
• Side connection of 80 mm diameter, matching the Alsident 50, 63 and 75 systems
• 1250 mm length lets the arm be positioned away from the ceiling duct outlet
• Full polyester finish applied by TGIC powder coating on all surfaces, inside included
• Increased durability in workshop, laboratory and production environments

Technical data

Applications

The base box is used wherever extraction arms are suspended from the ceiling above soldering benches, test and assembly lines or laboratory rows. Its length bridges the distance between the existing duct outlet and the desired arm position without relocating the ceiling penetration.

Compatibility and scope of delivery

Intended for Alsident extraction arms of the DN 50, 63 and 75 systems in ceiling versions. One base box is supplied per order unit, extraction arm and hood are not included.
