SMD adhesive one-component 30 ccm EFD cartridge - Loctite 3609-30ML
Components drifting out of position before the solder wave are a common defect source in through-hole assembly. One-component Loctite 3609 pre-fixes SMD parts and comes here in the larger 30 ccm EFD cartridge with 30 cm³, the stock size for longer production runs. It dispenses without mixing and suits medium to high output rates.
- Specialist dealer since 2009
- Invoice payment for regular customers
- Worldwide shipping
- Technical questions clarified with the manufacturer
Description
Surface-mount parts must hold their placement position until the populated board has passed the solder wave. Loctite 3609 is a one-component SMD adhesive for that pre-fixing step, supplied here in the larger 30 ccm EFD cartridge with 30 cm³ for extended dispensing runs.
Benefits
- One-component chemistry, no mixing and no pot life to monitor
- 30 cm³ stock package, fewer cartridge changes in series production
- High moisture resistance of the cured adhesive dots
- Long stencil and dispenser life during production runs
- High dot profile for reliable component pick-up at medium to high output rates
- Suitable for lead-free wave soldering with water-based and alcohol-based fluxes
Applications
Pre-fixing SMD components on the printed circuit board ahead of wave soldering, series production on automatic dispensing lines or semi-automatic dispensers, and repair or small-batch work where parts must be secured against movement.
Compatibility and scope of delivery
The 30 ccm EFD cartridge fits common dispensing systems with EFD cartridge holders and works with matching dispensing needles. The adhesive is released for lead-free wave soldering processes using water-based and alcohol-based fluxes. Scope of delivery: one Loctite 3609 cartridge containing 30 cm³.
Technical data
| Item number | WL37202 |
|---|---|
| Model | 3609-30ML |
| Manufacturer | Loctite |
| Product type | SMD adhesive, one-component |
| Package | EFD cartridge 30 ccm |
| Content | 30 cm³ |
| Processing | Dispensing technology, no mixing required |
| Weight | 0.1 kg |
| Weight | 0.050000 |
| HS-Code | 35061000 |
| GPSR manufacturer information | LOCTITE Erdbergstraße 29 AT-1030 Wien www.loctite-superkleber.at |
| Condition of article | New |
| Article authenticity | Original product |
| Country of Manufacture | Ireland |
