Short tips transfer heat more directly because the path from heater to joint is shorter. The TM60C301 uses that with a 5 mm tip length and a 0.5 mm conical point, which suits joints with high thermal drain on accessible surfaces. It self-regulates at 325-358 °C and fits the SHP-T hand piece of the TMT-5000S stations.
Soldering tip conical 0.5 mm short 5 mm T series - Thermaltronics TM60C301
THERMALTRONICS
Original product
Net price (excl. VAT)
€13.25
Item
WL38406
Manufacturer no.
TM60C301
Personal expert advice
Brand new
Specialist dealer since 2009
Original product
Worldwide shipping
Product data
Manufacturer no.TM60C301
ConditionNew
Article
WL38406
Frequently Bought Together
-
This Item:
€13.25
-
Soldering tip sharp bent 30° 0.4 mm T series 325-358 °C - Thermaltronics TM60B325
€13.25
-
Soldering tip hoof 60° 3.3 mm T series - Thermaltronics TM80DS525
€24.29
Total price
On ground planes and heavy copper the tip temperature of long, slim geometries drops away quickly. The Thermaltronics TM60C301 therefore uses a short body: 5 mm tip length with a 0.5 mm conical point. The short path between heating zone and contact point keeps heat recovery stable, with Curie point regulation working at 325-358 °C.
Benefits
- Short 5 mm tip length for rapid heat recovery on thermally demanding joints
- Conical 0.5 mm point for targeted contact with single pads and pins
- Self-regulating heater at 325-358 °C with no temperature preset
- Stable tip geometry with little tendency to flex under pressure
- RoHS compliant and lead-free capable
Technical data
| Item number | WL38406 |
| Manufacturer | Thermaltronics |
| Manufacturer item number | TM60C301 |
| Model | TM60C301 |
| Product series | T tip series, 325-358 °C |
| Temperature range | 325-358 °C |
| Type | Soldering tip |
| Tip shape | Conical |
| Tip length | 5 mm (0.2 in) |
| Tip width | 0.5 mm (0.02 in) |
| Suitable hand piece | SHP-T |
| Order unit | Piece |
| Dimensions with packaging (LxWxH) | 117 mm x 33 mm x 13 mm (4.6 in x 1.3 in x 0.5 in) |
| Weight | 0.1 kg |
| Design | RoHS compliant, lead-free |
Applications
Soldering of pads tied to ground planes, attaching shielding cans and contact tabs, general repairs on openly accessible board areas, cable and component work with raised heat demand.
Compatibility and scope of delivery
T series cartridge for the SHP-T hand piece and the Thermaltronics TMT-5000S-1 and TMT-5000S-2 soldering stations. One cartridge is supplied per order unit.
| Manufacturer Nr. | TM60C301 |
|---|---|
| Manufacturer | Thermaltronics |
| Weight | 0.100000 |
| GPSR manufacturer information | AMS Ltd, Unit 3 Norse Trade Park, Congleton CW12 1GW, www.ams-electronics.co.uk |
| Article authenticity | Original product |
| Condition of article | New |
| Position sensing | No |
